GE Fanuc RX7i Controller IC698CPE030

GE Fanuc IC698CPE030 PACSystem RX7i Rack CPU

The GE Fanuc IC698CPE030 is a high-performance CPU for the PACSystem RX7i. It runs user programs and controls I/O modules. It features a 600 MHz Pentium M processor with 64 MB RAM and 64 MB flash memory.

Key Features

• 600 MHz Pentium M processor
• 64 MB user RAM and 64 MB flash memory
• Supports 512 program blocks, max 128 KB per block
• I/O memory: 32 Kbits discrete, 32 KWords analog
• Two Ethernet ports (10/100 Mbps) with EGD, SRTP, Modbus TCP Server/Client
• One RS232, one RS485, and one Station Manager port
• Supports floating point math and Boolean logic
• Programming languages: Ladder, C, Structured Text, Function Block Diagram
• Web server and FTP support for remote monitoring
• Operating voltage: +5, +15, -12 VDC; current: 3.4 Amps
• Rack location: RX7i I/O slot
• VME64 architecture for fast data throughput

Technical Specifications

• Brand: GE Fanuc
• Series: PACSystem RX7i
• Part Number: IC698CPE030
• Application: RX7i PLC System
• CPU Memory: 64 MB RAM
• Flash Memory: 64 MB
• Program Blocks: 512, max 128 KB each
• Ethernet Data Rate: 10/100 Mbps
• Supported Protocols: EGD, SRTP, Modbus TCP/RTU, SNP, Serial I/O
• Ports: 2 Ethernet, 1 RS232, 1 RS485, 1 Station Manager
• Discrete I/O: 32 Kbits; Analog I/O: 32 KWords
• Voltage: +5, +15, -12 VDC
• Current Rating: 3.4 Amps
• Programming: Ladder, C, Structured Text, Function Block Diagram
