IC695PSD140 Earthing Strategies: 24V DC Common vs. Protective Ground in Industrial Control
In the realm of factory automation and PLC-based control systems, the decision to bond the 24V DC return (COM) to the chassis earth is a recurring engineering puzzle. This article provides a comprehensive analysis based on empirical data, official specifications, and field experience, guiding automation professionals through a structured decision-making process.
The Manufacturer’s Stance on Output Common Grounding
According to the official GE/IPC documentation (manual GFK-2932E), the 24V return terminal, designated as ‘0V’ or ‘COM’, maintains galvanic isolation from the protective earth (PE) lug through an internal network comprising a 1 MΩ resistor and a 4.7 nF capacitor. Consequently, a direct hardwired short between COM and the chassis is not a mandatory installation requirement. In fact, production tests confirm an insulation resistance exceeding 100 MΩ at 500 VDC between these points. However, the manual explicitly permits a direct ground connection if system noise immunity considerations demand it.
Distinguishing Protective Earthing from Functional Earthing
Protective earthing (PE) serves a critical safety function, providing a path for fault currents to safely trip overcurrent protection devices. In contrast, functional earthing (FE) establishes a stable signal reference and enhances electromagnetic interference (EMI) shielding effectiveness. The IC695PSD140’s COM terminal acts as a functional reference, not a safety conductor. Therefore, shorting COM to chassis merges these two distinct roles, necessitating a careful risk assessment. For example, a 24V DC output fault to PE can induce ground loops with currents reaching up to 5 A, potentially disrupting sensitive analog measurements.
Quantifying Noise and Ground Loop Risks
Field tests reveal that a direct short between COM and chassis can elevate common-mode noise from a modest 50 mV to a significant 120 mV peak-to-peak. This noise increase, observed across the 150 kHz to 30 MHz frequency band, directly impacts analog I/O accuracy and can degrade the performance of communication interfaces. Conversely, leaving the COM floating limits leakage current to a mere 0.3 mA through the internal RC network. As a result, for systems integrating both analog and digital circuits, many senior automation engineers advise against a permanent hard ground, especially considering that data from 120 installed panels indicates 78% of EMI complaints originated from grounded COM designs.
When Does a Direct Short Become Advantageous?
A direct short proves beneficial when powering long cable runs exceeding 30 meters. In such scenarios, the cable acts as an effective antenna; grounding one end can reduce radiated emissions by approximately 6 dBµV/m. Furthermore, if the system incorporates external 24V field devices with isolated returns, a common reference point becomes essential. In these cases, the short must be implemented at a single star point, ideally located near the power supply terminals, to limit circulating ground currents to less than 0.1 A during normal operation.
Safety Isolation and Dielectric Considerations
Prior to implementing a short, it is crucial to confirm that the 24V output meets SELV (Safety Extra-Low Voltage) requirements per IEC 61140. The IC695PSD140 is rated to withstand 1500 VAC for one minute between primary and secondary circuits. Tying COM to chassis references the entire 24V rail to PE, thereby altering the isolation coordination. Although the effective working voltage relative to ground shifts from 0V to 24V, it remains within SELV limits. However, unmitigated transient overvoltages up to 2 kV could couple directly to the logic side if not properly filtered.
Empirical Insights from OEM Installations
An independent survey of 50 OEM cabinets reveals diverse grounding practices: only 32% adopt a permanent COM-to-chassis short. Among those, 14% reported sporadic PLC resets, often attributed to high-frequency switching noise from servo drives. Conversely, 68% of installations preferred a removable jumper or a 100 Ω resistor for flexible grounding. This resistor approach effectively limits circulating current to 0.24 A while maintaining a low-impedance reference. Moreover, adding a 1 µF ceramic capacitor in parallel with the resistor offers enhanced suppression of 10-100 MHz interference.
A Structured Decision-Making Framework for Panels
To make an informed choice, begin by identifying all field devices sharing the same 24V bus and verifying their isolation ratings. Next, measure the AC voltage potential between COM and chassis using a true-RMS multimeter. If this value exceeds 1 Vrms, a direct short will significantly reduce common-mode interference. Subsequently, evaluate the total leakage current; if it surpasses 5 mA, consider an RC network instead of a solid wire connection. Finally, test the chosen configuration under maximum load (14 A) and monitor the terminal block temperature rise to ensure reliability.
Preferred Termination and Wiring Practices
For a reliable installation, use a dedicated 6 mm² green-yellow wire for the PE connection from the supply mounting screw. For the COM short, employ a 1.5 mm² insulated wire with a fork terminal, torqued to 0.8 N·m. The short point should always be placed immediately after the output fuse (rated 15 A, fast-acting) to ensure the fuse clears any fault before the ground path is compromised. Periodic thermal imaging confirms that terminal temperatures remain below 45°C under rated operating conditions.
Regulatory Compliance with UL and CSA Standards
UL 61010-1 permits a functional earth connection provided the circuit remains Class 2 compliant. The IC695PSD140 holds a UL recognition mark with a maximum output power of 336 W at 60°C ambient temperature. Shorting COM to PE does not void the UL listing if total leakage remains under 3.5 mA. However, installers must add a warning label stating: “Functional ground – do not remove for safety.” Similarly, CSA C22.2 No. 14 requires a bonded neutral for DC systems above 60V, a condition not applicable to this 24V supply.
Field Failure Analysis: Case Studies in Action
Case A: An automotive plant experienced analog signal drift of ±0.5% after the COM was permanently grounded. Removing the short restored accuracy to ±0.05% within 24 hours, preventing a major production line issue. Case B: A water treatment facility faced intermittent Profibus-DP communications with bit errors at 12%. Adding a 220 Ω resistor between COM and chassis reduced errors dramatically to 0.02%. These case studies clearly demonstrate that a universal grounding policy is technically unsound; each system requires an individual assessment.
Final Verdict: Engineering Judgement Prevails
In conclusion, grounding the IC695PSD140’s 24V return is a design choice, not a mandatory safety rule. Data from over 200 installations indicate that 60% operate reliably with an isolated COM. Only when high-frequency drives or long cables are present does a short become advantageous. Therefore, applying a systematic test protocol and prioritizing noise immunity over convention is the prudent path. As an automation engineer, your empirical measurements serve as the ultimate guide for this critical decision.
Practical Application: The Remote I/O Cabinet Solution
Consider a remote I/O cabinet situated 40 meters from the main PLC controller, housing both analog input modules and a Profibus-DP communication processor. The cabinet is powered by an IC695PSD140. In this scenario, long cable runs and potential for ground potential differences (GPDs) exist. The recommended approach involves implementing a star-point grounding scheme. Connect the COM terminal to the chassis via a 100 Ω resistor in parallel with a 1 µF capacitor at the power supply output. This arrangement provides a low-impedance path for high-frequency noise while limiting DC ground currents. Following this method, the Profibus-DP communication error counters remained stable, and analog readings maintained an accuracy of ±0.1% over a six-month period, confirming the efficacy of a flexible grounding strategy.
Frequently Asked Questions (FAQ)
- Q: Is shorting the 24V COM to chassis mandatory for safety?
A: No, it is not mandatory. The COM terminal is isolated from PE via a 1 MΩ resistor and 4.7 nF capacitor. A hard short is a design choice based on noise immunity or referencing requirements, not a safety directive. - Q: What is the primary risk of a direct COM-to-chassis short?
A: The main risks are ground loops, which can induce currents up to 5 A and elevate common-mode noise from 50 mV to 120 mV peak-to-peak, degrading analog I/O and communication performance. - Q: When should I consider a direct short?
A: Consider a direct short when powering long cable runs (>30 meters) to reduce radiated emissions, or when external field devices with isolated returns require a common reference point. Always implement it at a single star point. - Q: What is the recommended alternative to a permanent short?
A: A removable jumper or a 100 Ω resistor in parallel with a 1 µF capacitor offers flexibility. This RC network limits circulating current and suppresses high-frequency interference, providing a balanced solution for many installations. - Q: Does shorting COM to PE void the UL listing?
A: No, it does not void the UL listing, provided total leakage current stays under 3.5 mA and the circuit remains Class 2 compliant. However, a warning label is required to indicate the functional ground.
