Schneider Electric 140DAI55300 115V AC Discrete Input Module

Schneider Electric 140DAI55300 115V AC Input Module – 32 Points

The Schneider Electric 140DAI55300 is a Modicon Quantum input module. It works with 115V AC signals. This unit gives you 32 discrete inputs in a standard size. It offers clear LED indicators and strong isolation.

Main Features of the 140DAI55300

• Brand & Model: Schneider Electric 140DAI55300 – genuine Modicon Quantum part.
• Inputs: 32 points, 115V AC. They come in 4 isolated groups. Each group has 8 inputs.
• ON Voltage: Module turns ON from 79 to 132V AC. It turns OFF below 20V AC.
• Current Draw: Each input uses 11.1 mA (60 Hz) or 13.2 mA (50 Hz).
• Speed: Off-On response takes 0.75 to 4.9 ms. On-Off takes 7.3 to 12.3 ms.
• Isolation: 1780V isolation between groups. Also isolated from the backplane.
• Power Use: Needs 250 mA from the bus. Dissipates 10.9 W max.
• LEDs: 32 green LEDs show input status. One green LED for bus active. One red LED for faults.
• Software: Works with Unity Pro, ProWORX 32, and Concept.

Tough Environment Ratings

• Heat: Runs from 0°C to 60°C (32°F to 140°F).
• Cold Storage: Stores from -40°C to 85°C (-40°F to 185°F).
• Static Protection: Handles 4kV contact and 8kV air discharge.
• Radio Fields: Resists interference up to 10 V/m.
• Humidity: Works at 95% humidity, no condensation.
• Height: Use up to 5000 meters altitude.
• Safety: UL, CSA, cUL, and FM approved. CE marked.

Easy Installation & What You Get

• Size: Standard Quantum format. Weight 0.33 kg (0.73 lb).
• Wiring: Four separate groups make wiring simple.
• Box Content: One new 140DAI55300 module. Factory sealed.
• Box Size: 30 x 4.5 x 31.2 cm. Total weight 448 grams.
• Stock: We have many units ready to ship.
• Shipping: We use FedEx, UPS, and DHL. We ship in 5 days.
• Returns: You can return it within 30 days.

Quick FAQ

• Which software works with the 140DAI55300? It runs on Unity Pro, ProWORX 32, and Concept.
• What is the max leakage current? It handles up to 2.1 mA leakage.
• Can I use 230V with this module? No, it only works with 115V AC. Higher voltage will break it.
• Are the inputs isolated? Yes, between groups. But not between points in the same group.
• What do the LEDs tell me? Green LEDs show each input on/off. The red LED means a fault.
• How do I get the manual? Email us and we will send the PDF.
