Schneider Electric 140CRP93200 Quantum Redundant Module

Schneider Electric 140CRP93200 Redundant RIO Head-End Adaptor Module

The Schneider Electric 140CRP93200 is a redundant RIO head-end adaptor module. It works with the Modicon Quantum automation platform. This module sits in the main processor rack. It uses two cables for network reliability. If one cable fails, the other keeps working. The 140CRP93200 manages up to 31 remote drops on the S908 network.

Main Specifications

• Product range: Modicon Quantum automation platform
• Product type: RIO head-end adaptor with redundant cables
• Works with: Quantum 200/500/800 series and Symax systems
• GTIN: 3595861133761
• Category: US1PC2118155
• Discount schedule: PC21

Network Features

• Supports up to 31 remote drops on one network
• Speed: 1544 Mbit/s for fast data transfer
• I/O per drop: 64 input words and 64 output words
• Signal range: 35 dB dynamic range
• Cable type: 75 Ohm coaxial cable
• Isolation: 500 V DC between center and ground

Connector and Power

• Two elbowed female F-type connectors for redundant cables
• Power use: 3 W for both channels
• Bus current: 750 mA for both channels
• Startup checks: memory and LAN controller tests
• CE marking for Europe

Environmental Ratings

• Working temperature: 32 to 140 °F (0 to 60 °C)
• Storage temperature: -40 to 185 °F (-40 to 85 °C)
• Humidity: 95% with no condensation
• Max altitude: 16404 feet (5000 meters)
• Static protection: 4 kV contact, 8 kV air
• Field protection: 9.1 V/m at 80-1000 MHz

Certifications

• FM Class 1 Division 2 for hazardous areas
• UL 508 certified
• CUL certified for Canada
• CSA C22.2 No 142 compliant
• Meets IEC 801-2 and 801-3 standards

Frequently Asked Questions

• What is the 140CRP93200 used for? It is the main module in the processor rack with redundant cable support. It manages all remote I/O drops on the S908 network.
• What is the difference between 140CRP93100 and 140CRP93200? The 93100 has one connector for a single cable. The 93200 has two connectors for redundant cables.
• How many drops can it handle? It can handle up to 31 remote drops on one network.
• What cable do I need? You need 75 Ohm coaxial cable for the S908 network.
• How much I/O per drop? Each drop handles 64 input and 64 output words.
• What temperature range works? It works from 0 to 60°C (32 to 140°F).
• Is it safe for hazardous areas? Yes, it has FM Class 1 Division 2 certification.
• Why use redundant cables? Redundant cables provide backup. If one cable fails, the network keeps working.
