Schneider Electric 140CRA21210 – DIO Drop Interface

Schneider Electric Modicon Quantum 140CRA21210 DIO Drop Interface

Core Technical Specs

• Schneider Electric AC-powered DIO drop interface.
• Single-port design for remote I/O links.
• Uses 115/230V AC power (85-276V, 47-63Hz).
• Gives 5.1V DC output with 3A power.

Power & Electrical Info

• Rated voltage: 115/230V AC (50VA power).
• Max current: 0.2A at 115V, 0.4A at 230V.
• Inrush current: 10A at 115V, 20A at 230V.
• Needs a 1.5A fuse.
• Uses about 11W of power.
• Has short-circuit and overvoltage protection.

System & I/O Details

• Handles 30 input and 32 output words.
• Works with many backplanes: 2, 3, 4, 6, 10, or 16-slot.
• Uses 7-pole terminal block for wires.
• Standard size for easy rack mounting.
• Has startup and runtime diagnostics.

Environment & Durability

• Works in 0 to 60°C (32 to 140°F).
• Stores in -40 to 85°C (-40 to 185°F).
• Handles up to 95% humidity (no condensation).
• Good for heights up to 5000 meters.
• Resists ESD: 4kV contact, 8kV air.
• Resists EMI: 9.1V/m (80-2000MHz).

Common Questions (FAQ)

• Q: Does it work with all Quantum backplanes?
  A: Yes. It fits 2, 3, 4, 6, 10, or 16-slot backplanes.
• Q: What power does it need?
  A: 115/230V AC (85-276V, 47-63Hz).
• Q: Does it have protection?
  A: Yes. It has short-circuit and overvoltage protection.
• Q: What diagnostics does it have?
  A: It checks RAM and data during startup and runtime.
• Q: What are shipping and return rules?
  A: We ship in 5 days. We allow 30-day returns.
