Schneider Electric 140CPS21100 Power Supply Module

Schneider Electric 140CPS21100 Power Supply Module for Modicon Quantum

Core Technical Specifications

• Brand & Model: This module comes from Schneider Electric, and its specific part number is 140CPS21100.
• Input Power: It requires a 24V DC power source, with an acceptable range from 20 to 30 volts DC.
• Output Performance: The module provides a regulated 5.1 Volts DC with a current output ranging from 0.3 to 3.0 Amperes.
• Protection Features: It includes built-in internal protection against both output overload and overvoltage conditions.
• Power Buffer: It can handle brief input power interruptions, up to 1ms at 20V, ensuring system stability.

Environmental Durability & Compliance

• Operating Temperature: The unit operates reliably in temperatures from 0°C to 60°C (32°F to 140°F).
• Noise Immunity: It demonstrates strong resistance to electromagnetic interference, tested at 10 V/m from 80 to 2000 MHz.
• ESD Protection: The module is protected against electrostatic discharge up to 8 kV in air.
• Safety Certifications: It carries important safety approvals including cUL and is suitable for FM Class 1 Division 2 environments.

Installation & Physical Details

• Module Format: It uses a standard module format designed for easy installation in a Modicon Quantum rack.
• Status Indication: A single green LED provides clear “PWR OK” status signaling at a glance.
• Fuse Requirement: For input protection, use a 2.5 A, slow-blow type fuse as recommended.
• Power Calculation: You can calculate power dissipation using the formula: 2 Watts + (3 x Iout), where Iout is the output current in Amps.

Packaging & Shipping Information

• Package Contents: You will receive one (1) Schneider Electric 140CPS21100 power supply module.
• Package Dimensions: The shipping box measures 31.2 cm L x 16.3 cm H x 4.5 cm W.
• Shipping Weight: The total parcel weight is approximately 729 grams.
• Dispatch & Logistics: We process orders quickly and ship via global carriers like FedEx, UPS, and DHL within 5 business days.

Frequently Asked Questions (FAQ)

• Q: Is this module brand new and genuine?
  A: Yes, we supply only 100% brand new and original Schneider Electric 140CPS21100 modules.
• Q: What is the input voltage range?
  A: The input range is 20 to 30 Volts DC, with a nominal rating of 24V DC.
• Q: How much current can the output provide?
  A: The 5.1V DC output can deliver up to 3.0 Amperes of current.
• Q: Do you have this item in stock?
  A: Yes, we maintain healthy stock levels for fast fulfillment.
• Q: What is your return policy?
  A: We support a 30-day return policy for your peace of mind.
