Bently Nevada 330104-03-12-10-02-00 3300 XL 8 mm Proximity Probe

Product Description

A reliable sensor for industrial use, the Bently Nevada 330104-03-12-10-02-00 3300 XL 8 mm Proximity Probe checks machine movement without contact. It uses strong materials to work well in tough spots.

Model Suffix Explained

The full model 330104-03-12-10-02-00 means:

330104: Base type – 3300 XL 8 mm probe with M10 x 1 thread and armor.
03: Unthreaded part length – 30 mm.
12: Case length – 120 mm.
10: Total cable length – 1.0 m (3.3 ft).
02: Connector – Mini ClickLoc coaxial, standard cable.
00: No extra approvals needed.

Key Specs

Brand: Bently Nevada
Type: 3300 XL 8 mm Proximity Probe
Materials: Tip (PPS plastic); case (303/304 stainless steel).
Electrical:
DC resistance: 7.59 ± 0.50 Ω (1.0m cable).
Output resistance: 50 Ω.
Power: -17.5Vdc to -26Vdc (non-incendive); -23Vdc to -26Vdc (with barriers).
Temp Range: Probe works from -55°C to +232°C (T1, EPL Ga/Gc).

Fit & Setup

Works with 3300 XL 8 mm Proximitor Sensors and extension cables. Best for AISI 4140 steel targets. Set gap at 1.27 mm (50 mils) with 10 kΩ load.

Safety Ratings

Safe (ia): Class I Zone 0 (AEx/Ex ia IIC T5…T1 Ga); Class I Div 2 (A-D).
Non-spark (nA/ec): Class I Zone 2 (AEx/Ex nA/ec IIC T5…T1 Gc); Class I Div 2 (A-D).

What’s Included

Probe unit and user manual (standard package).
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
