IC660BBD023 GE Fanuc I/O Block

GE Fanuc IC660BBD023 Genius Block I/O Module

Technical Specifications

• Brand: GE Fanuc
• Model: IC660BBD023
• Series: Genius I/O
• Voltage: 24 VDC
• Channels: 16 circuits
• Load Current: 2 Amps per circuit
• Configuration: Input, output, or tristate
• Input Filter: 10-100 ms selectable
• Leakage Current: 1.9 mA maximum
• Heat Dissipation: 68.8 Watts at 2A
• Temperature: 0 to 60°C
• Weight: 1.8 kg
• Dimensions: 22.4cm x 9.05cm x 11.23cm

Key Features

• Works with 2-wire and 3-wire sensors
• Provides short circuit protection
• Detects overtemperature conditions
• Finds failed switches and open wires
• Shows status with LED indicators
• Offers selectable input filter times
• Includes two serial communication ports
• Receives power from field devices

Questions & Answers

• What sensors work with this module?
  Both 2-wire and 3-wire solid state sensors.
• How much output current per circuit?
  2 Amps maximum steady state current.
• What input filter times available?
  Selectable from 10ms to 100ms range.
• What safety features included?
  Short circuit, overload, and temperature protection.
• Where can I install this module?
  Indoor locations with proper protection only.
• What communication ports available?
  Two serial ports and shield in/out ports.
