IC200NDD101 – NANO Controller GE Fanuc

GE Fanuc IC200NDD101 Nano Controller

The IC200NDD101 is a Versamax Nano PLC. It has 6 DC inputs and 4 DC outputs. This compact controller uses 24VDC power. It carries cULus and CE marks.

Key Features

IC200NDD101 has flexible inputs. They work as standard or high-speed counters. Inputs support positive and negative logic. Outputs are transistor type with isolation.

The controller has an RJ45 port. This connects to programming computers. All points have LED status lights. System LEDs show power and status.

Technical Specifications

Electrical Data

Holdup time is 10 ms at 19.2VDC. Inrush time is 10 ms at 30VDC. Outputs control contactors and valves. All outputs have field-logic isolation.

Temperature range is 0-55°C. Meets T4 temperature code. Not for hazardous locations. Keep within temperature limits.

Programming

Use RJ45 port for programming. Connect to computers easily. Monitor through LED indicators. Simple setup and operation.

FAQ

How many I/O points?
6 inputs and 4 outputs.

What voltage?
24VDC operating voltage.

Programming port?
RJ45 serial port.

Certifications?
cULus and CE certified.

New products?
Yes, genuine GE Fanuc only.

Shipping time?
Ships in 5 business days.

Returns?
30-day return policy.
