GE Fanuc IC695FTB001 Fiber Terminal Block
The IC695FTB001 expands I/O for GE Fanuc PACMotion RX3i systems. It uses fiber optic cables for strong noise protection.
Technical Specifications
| Brand | GE Fanuc |
| Model | IC695FTB001 |
| Series | PACMotion RX3i |
| Power Input | 19.2-28.8V DC |
| Input Current | 0.45A at 24V |
| 5V Output Current | 0.5A maximum |
| Communication | Fiber Optic |
| Max Cable Length | 100 meters |
| Mounting | 35mm DIN Rail |
I/O Configuration Table
| I/O Type | Voltage | Quantity |
| Digital Outputs | 24V DC | 8 points |
| Digital Inputs | 24V DC | 16 points |
| Differential I/O | 5V DC | 4 points |
| Digital Inputs | 5V DC | 8 points |
| Analog Inputs | +/-10V | 2 channels |
| Analog Outputs | +/-10V | 2 channels |
Key Features
- Fiber optic communication
- Removable terminal blocks
- DIN rail mounting
- Overload protection
- Encoder detection
- Motion control functions
- Noise immune design
Motion Control Features
- Marker inputs
- Touch probe inputs
- Home switches
- Overtravel limit switches
- Encoder open-circuit detect
- Flexible I/O assignment
Power Consumption
- 4W at 5V DC (80mA)
- 2.16W at 24V DC (90mA)
- 7W at 5V DC (140mA)
- 1.2W at 24V DC (50mA)
- Low power design
Installation Guide
- Mount on 35mm DIN rail
- Use vertical position
- Prevent overheating
- Max cable: 100 meters
- Check fiber connections
- Follow power ratings
Physical Dimensions
- Width: 141.2 mm
- Height: 125.5 mm
- Depth: 62.5 mm
- Compact design
- Space saving
Shipping Information
- Secure packaging
- FedEx, UPS, DHL
- Fast processing
- Tracking number
- Global delivery
Common Questions
- What systems use this? PACMotion RX3i systems.
- How many inputs? 16 digital plus analog.
- Power requirements? 19.2-28.8V DC.
- Cable length? 100 meters maximum.
- Mounting type? 35mm DIN rail.
