GE Fanuc Server Module IC695EIS001

GE Fanuc IC695EIS001 RX3i IEC 104 Server Module

Product Overview

The IC695EIS001 is an IEC 104 server module for RX3i PACSystems.

It allows the controller to act as a server on IEC 60870-5-104 networks.

The module supports up to 6144 IEC 104 points per module.

It enables data exchanges with IEC 104 client devices over TCP/IP connections.

The module has 2 auto-sensing 10/100 Mbps Ethernet ports and supports line, star, and daisy-chain topologies.

An RS-232 station manager interface supports data rates from 1200 to 115200 bps.

The IC695EIS001 is hot-swappable and requires 0.840 Amps at 3.3V DC.

Technical Specifications

Product Type: IEC 104 server module

Compatibility: RX3i PACSystems

Ethernet Ports: 2 x 10/100 Mbps

Serial Port: RS-232

Serial Data Rates: 1200–115200 bps

IEC 104 Points per Module: 6144

IEC 104 Clients per RX3i CPU: 4

IEC 104 Modules per RX3i CPU: 4

Power Requirement: 0.840 Amps at 3.3V DC
