GE Fanuc IC697MDL253 24 Volt AC Input Module

GE Fanuc IC697MDL253 Series 90-70 32-Point AC Input Module

Product Overview

The IC697MDL253 is a 32-point AC input module for industrial PLC racks.

GE Fanuc designs this module for reliable factory automation I/O.

Module operates at 24 V AC and supports phased wiring.

Use the four isolated groups to separate signals by phase or zone.

Technical Specifications

Brand: GE Fanuc

Series: Series 90-70

Part Number: IC697MDL253

Product Type: Input Module

Rated Voltage: 24 V AC

Inputs: 32 points, four groups of eight

Input Current (on): 10 mA

Leakage Current (off): 2 mA

Current Required: 0.30 A

Frequency: 47–63 Hz

Key Benefits

Isolate signals by group to simplify phased wiring.

Fast 20 microsecond filter for clean input detection.

Per-point LEDs speed troubleshooting and system checks.
