GE Fanuc IC660EBR100 Electronic Assembly

GE Fanuc IC660EBR100 Genius Electronic Assembly

The IC660EBR100 from GE Fanuc Automation is a relay output module for the Genius I/O system. Specifically, it delivers robust and reliable switching control for demanding industrial applications. Furthermore, this electronic assembly organizes outputs into logical groups for efficient power management.

Product Overview & Core Specifications

• Brand: GE Fanuc Automation
• Model: IC660EBR100
• Series: Genius I/O Block Series
• Product Type: Electronic Assembly (Relay Output)
• Output Configuration: 16 relay outputs arranged in 4 groups of 4.
• Output Rating: 2 Amps maximum per circuit.
• Switching Capacity: In addition, it offers a maximum of 60 Watts or 125 VA per circuit.
• Output Voltage Range: Moreover, it supports 5 to 250 V AC or 5 to 220 V DC.

Electrical & Environmental Specifications

• Input Power: 115 V AC (93-132V) or 230 V AC (185-265V) selectable.
• Power Consumption: Typically, it requires 87 mA at 115 V AC.
• Heat Dissipation: Consequently, the maximum dissipation is 10.1 Watts with all 16 outputs on.
• Frequency: Accordingly, it operates at 47 to 63 Hz.
• Minimum Load: For optimal performance, a 10 mA load is recommended for reliable contact operation.
• Operating Temperature: Designed for reliability, it is rated for 0°C to 60°C environments.
• Storage Temperature: Similarly, it can be safely stored from -40°C to 100°C.
• Humidity: Finally, it withstands 5% to 95% relative humidity, non-condensing.

Frequently Asked Questions (FAQ)

• How are the 16 relay outputs organized?
  Specifically, outputs are arranged in 4 isolated groups of 4 relays each for flexible circuit design and fault isolation.
• What is the maximum load per output relay?
  As a result, each relay can switch a load of up to 2 Amps at 250V AC.
