GE Fanuc IC660BBS100 I/O Block

GE Fanuc IC660BBS100 Isolated I/O Block

The IC660BBS100 is an isolated I/O block from GE Fanuc’s Genius I/O series. It provides eight circuits in four isolated groups. Each group contains two circuits that work with 115VAC or 125VDC. This versatile block can be configured as input, output, or mixed I/O.

Technical Specifications

• Brand: GE Fanuc
• Model: IC660BBS100
• Series: Genius I/O
• Number of Circuits: 8 circuits
• Circuit Groups: 4 isolated groups of 2
• Voltage Rating: 115VAC or 125VDC
• Current Rating: 2 Amps per circuit
• Isolation Rating: 250V between groups
• Heat Dissipation: 16.8 Watts
• Weight: 4 pounds

Installation & Wiring

• Use standard screwdrivers
• Accepts #12 AWG wire
• Accepts #22 AWG wire
• Fits 0.27″ ring terminals
• Works with #6 screw size
• Easy field wiring
• Simple terminal connections
• Backward compatible design

Operating Conditions

• Work Temperature: 0°C to 60°C (32°F to 140°F)
• AC Voltage Range: 93-132 VAC
• DC Voltage Range: 105-132 VDC
• Frequency Range: 47-63 Hz
• Isolation: 250V continuous
• Peak Current: 15A at 35°C

FAQ

• How many circuits does it have?
  It has 8 circuits in 4 isolated groups.
• What protection features?
  Electronic fusing, thermal protection, and short-circuit shutdown.
• What voltages does it support?
  It works with 115VAC and 125VDC systems.
• Can I mix inputs and outputs?
  Yes, it can be input-only, output-only, or mixed.
• What is the replacement model?
  This model has been replaced by IC660BBS102.
• What tools needed for wiring?
  Standard screws and screwdrivers are sufficient.
