GE Fanuc IC200CPU001 CPU Module

GE Fanuc IC200CPU001 CPU Module

Main Features

• 34K bytes of user memory
• 2048 discrete inputs and 2048 outputs
• Two serial communication ports
• Works with ladder logic programming
• Battery backup for clock and memory
• Fast 1.8 ms per K scan time
• Handles math calculations

Technical Details

• Brand: GE Fanuc
• Model: IC200CPU001
• Series: VersaMax
• Memory: 34 KB
• Inputs: 2048 points
• Outputs: 2048 points
• Internal Bits: 1024 points
• Ports: RS-232 and RS-485
• Protocols: Modbus, SNP
• Power: 140 mA at 5V

Memory Info

• 34K for user programs
• Battery keeps memory safe
• 32 Modbus registers
• Stores analog data

Communication

• Two serial ports
• Works with HMIs
• Connects to SCADA
• Modbus protocol

Programming

• Use Logic Developer software
• Front run/stop switch
• LED status lights
• PID control blocks

Common Questions

• What software does it use?
• How many inputs and outputs?
• What communication protocols?
• Is the clock battery backed?
• What is the scan time?
