GE Fanuc – IC200CHS112 I/O Terminal Module

GE Fanuc IC200CHS112 Relay Base

The IC200CHS112 adds relay outputs to your system. It works with the IC200MDL750 module. This base has 50 terminals. It can switch high power devices.

Main Features

Relay Details

Fast switching relays. They turn on in 15ms. Turn off in 5-10ms. Can switch 18,000 times per hour.

Works in tough conditions. Temperature range: -40 to 70°C. Humidity range: 35 to 85%. Very reliable performance.

Power Info

Needs 24V DC power. Connect to terminals B17-B18. Can switch 120W motors. Handles 240W heaters.

Good for many devices. Controls motors and lights. Runs solenoids and valves. Safe and reliable.

Setup Guide

Works with IC200MDL750 module. Uses points 17 to 32. Comes with ribbon cable. Easy to connect.

Also works with IC200MDL740. Simple installation. Just plug and play. Quick setup time.

Questions & Answers

What module works with this base?

Made for IC200MDL750 module.

How many wiring points?

50 terminals for your wires.

What power supply needed?

24V DC power on B17-B18 terminals.

How much current?

8 Amps for switching and running.

Comes with cable?

Yes, includes connection ribbon cable.

How long do relays last?

100,000 switches minimum.
