GE Fanuc IC200ALG320 Analog Output Module

The IC200ALG320 controls output signals. It has 4 output channels. Sends 4-20 mA current signals. Made by GE Fanuc, now Emerson.

Product Details

• Brand: GE Fanuc
• Model: IC200ALG320
• Series: VersaMax
• Channels: 4 outputs
• Current Output: 4-20 mA
• Resolution: 12-bit
• Update Speed: 0.3 ms
• External Power: 18-30 VDC needed
• Accuracy: 0.3% typical
• Status Lights: 2 LEDs
• Backplane Power: 50 mA max

Main Features

• Controls 4-20 mA signals
• Very fast 0.3 ms updates
• Good 12-bit resolution
• Two status lights
• Finds power problems
• Holds last state
• Safe isolation
• Easy to wire

Safety Protection

• Finds power loss
• Holds last values
• Safe electrical isolation
• Good for tough places
• Checks field power
• Shows faults quickly
• Stops signal jumps

Common Uses

• Control valves
• Run VFD drives
• Move dampers
• Panel meters
• Data loggers
• Signal repeaters
• Loop controls

What You Get

• One output module
• Safe packaging
• Guide papers
• Fast shipping
• Carrier choice

Questions Answered

• Output type? 4-20 mA
• How many channels? 4
• Need extra power? Yes
• Resolution? 12-bit
• Update speed? 0.3 ms
• Status lights? 2 LEDs
• Fault protection? Yes
