Flexem FPad716 Industrial IoT HMI Panel

Introducing the Flexem FPad716 Next-Generation Industrial IoT HMI

Key Features of the FPad716 HMI

• The device boasts a 15.6-inch TFT LCD with Full HD 1920×1080 resolution.
• It provides wide viewing angles of 85°/85°/85°/85° (Top/Bottom/Left/Right).
• You get rich 24-bit color depth and a bright 250 cd/m² LED-backlit display.
• Operation relies on a reliable 4-wire industrial resistive touch screen.
• The core is a high-speed quad-core 64-bit ARM Cortex-A55 CPU at 2.0 GHz.
• Graphics are handled by an integrated ARM Mali G52 GPU.
• It offers substantial 16GB eMMC storage and 2GB DDR4 RAM.

Detailed Technical Specifications

• Brand & Model: Flexem FPad716
• Display: 15.6″ 16:9 TFT LCD, 1920×1080, 24-bit, 250 cd/m²
• Touch Panel: 4-wire Resistive (Industrial Grade)
• Processor: 4-core ARM Cortex-A55 @ 2.0GHz
• Graphics: ARM Mali G52
• Memory: 16GB eMMC + 2GB DDR4
• Communication Ports:
  • Ethernet: 2 x Gigabit (10/100/1000M)
  • USB: 2 x USB 3.0 Type-A
  • Serial: COM1 (RS232/485/422), COM2 (RS485/422), COM3 (RS232)
  • Video: HDMI 2.0A
  • Optional: WiFi, 4G Module
• Environmental Ratings:
  • Operating Temperature: -10°C to +60°C
  • Storage Temperature: -20°C to +70°C
  • Humidity: 10-90% RH (Non-condensing)
  • Front Protection: IP65 / NEMA-rated Panel
  • Vibration Endurance: 10-25Hz, 2G, 30min (X,Y,Z)
• Power System:
  • Input: DC 24V (Range: 18V-28V)
  • Rated Power: < 18W
  • Power Interruption Tolerance: < 5ms
  • Protection: Isolated adapter with surge protection
• Mechanical & Certifications:
  • Housing: Non-ferrous Alloy
  • Installation: Flush-mounted
  • Cutout: 380 x 245 mm
  • Dimensions: 394 x 256 x 31 mm
  • Weight: ~2500g
  • Cooling: Natural Convection
  • OS: Linux
  • Certifications: CE, RoHS

Installation & Packaging Information

• Prepare a panel cutout of 380mm x 245mm for flush mounting.
• Ensure the operating environment is within the specified temperature and humidity ranges.
• Connect the provided isolated 24V DC power adapter for safe operation.
• Utilize the rear I/O ports for Ethernet, USB, and serial device connections.

• Package Includes:
  • 1 x Flexem FPad716 HMI Unit
  • 1 x Isolated 24V DC Power Adapter
  • Mounting Clips and Hardware
  • Quick Start Guide
• Shipping: We ship globally via major carriers like FedEx, UPS, and DHL.
• Stock Status: All items are brand new, original, and in stock.

Frequently Asked Questions (FAQ)

• Q: What is the operating temperature range of the FPad716?
  A: The FPad716 is designed to operate reliably in temperatures from -10°C to +60°C.
• Q: What type of touch screen does it use?
  A: It uses a durable 4-wire industrial resistive touch screen, suitable for harsh environments.
• Q: Does it have built-in WiFi or 4G?
  A: WiFi and 4G are optional features. The standard unit has dual Gigabit Ethernet for primary connectivity.
• Q: What is the power supply requirement?
  A: It requires a DC 24V power input, with a working range of 18V to 28V.
• Q: How soon can you ship the unit?
  A: We process orders quickly and typically ship within 5 business days.
• Q: What is your return policy?
  A: We support a 30-day return policy for your peace of mind. Please contact our sales team for details.
