Bently Nevada 330172-00-20-10-02-00 Vibration Probe
5mm industrial vibration sensor with armored cable. Made in USA. Works with Bently 3300 monitoring systems.
Probe Size
5mm
5mm
Cable Length
1.0m (3.3ft)
1.0m (3.3ft)
Thread Type
1/4-28 UNF
1/4-28 UNF
Temp Range
-35°C to +177°C
-35°C to +177°C
Key Features
- Stainless steel armored construction
- PPS probe tip material
- ClickLoc coaxial connector
- 2.0″ case length
- No agency approvals required
Model Number Explained
330172: Base model
00: 0″ unthreaded
20: 2.0″ case
10: 1.0m cable
02: ClickLoc
00: No approvals
00: 0″ unthreaded
20: 2.0″ case
10: 1.0m cable
02: ClickLoc
00: No approvals
Installation Guide
- Use #3 drill bit for mounting hole
- Max thread depth: 0.375″ (9.5mm)
- Torque to 45 in-lbs (5.1 N·m)
- Maintain 1″ (25.4mm) cable bend radius
Technical Specifications
| Power Supply | -17.5V to -26V DC |
| Current Draw | 12mA max |
| Case Material | 304 Stainless Steel |
| Weight | 0.323 kg (0.71 lbs) |
Typical Applications
Rotating Machinery
Industrial Turbines
Compressors
Pump Systems
Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
