Bently Nevada 330173-00-09-10-02-CN | 3300 5mm Probe

Bently Nevada Extended-Range Vibration Probe

90mm stainless steel vibration sensor with precision measurement for critical industrial applications.

Core Specifications

Manufacturer: Bently Nevada
Model: 330173-00-09-10-02-CN
Case Length: 90mm (09 option)
Cable: 1.0m FEP-insulated
Thread: M8×1 standard
Weight: 0.323kg

Electrical Performance

• Power: -17.5 to -26 VDC (±0.2V)
• Current: 12mA max consumption
• Output: 50Ω resistance
• DC Resistance: 7.59±0.50Ω
• Sensitivity: <2mV/V variation

Robust Construction

✓ PPS probe tip for chemical resistance
✓ 304 stainless steel case for durability
✓ 222N tensile strength at connections
✓ Gold-plated connectors for reliable signal

Environmental Ratings

Temp Range: -35°C to +177°C
Min Bend Radius: 25.4mm
Torque Range: 5.1-7.3N·m
Seal Warning: Avoid below -34°C

Installation Guide

Mount with M8×1 thread at 1.27mm target gap. Apply 5.1N·m installation torque.

System Compatibility

Designed for Bently Nevada 3300/3500 monitoring systems. Ideal for generators, turbines, and compressors operating at 1800-3600 RPM.

Certifications

Country-specific approvals included (CN option). Meets industrial safety standards.

Package Contents

Vibration probe with 1.0m cable, ClickLoc connector, and documentation. Optional COO available.

Quality Commitment

1-year warranty against defects. Precision manufactured in USA.

Industrial Application

Monitors hydroelectric turbine vibrations at 150 RPM, detecting 0.05mm displacements with ±1% accuracy in harsh environments.

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
