Bently Nevada | 330104-00-07-50-02-05 | Proximity Armored Probe

Bently Nevada 3300 XL 8mm Armored Probe (Model: 330104-00-07-50-02-05)

Industrial-grade protected sensor for tough environments. Made in USA with 5m armored cable and global safety approvals.

Key Features

• Armored design for cable protection
• 5 meter (16.4 ft) cable length
• M10x1 threaded stainless steel body
• Wide temperature range: -55°C to +232°C
• 2mm measurement range

Model Breakdown

Technical Specs

• Tip material: Durable PPS plastic
• Seal: Viton O-ring (-34°C min)
• Resistance: 8.73Ω ±0.50
• Power: -17.5V to -26V DC
• Output: 50Ω resistance

Installation

Works with 3300 XL systems. Max 305m total cable length. Optimal gap: 1.27mm (50 mils).

Safety Certifications

• ATEX Zone 0/Zone 2
• IECEx certified
• CSA approved
• Class I, II, III hazardous areas

What’s Included

• 1 armored probe with 5m cable
• ClickLoc connector
• Installation documentation

Ideal For

Perfect for oil/gas, mining, and heavy industry where cable damage is a concern.

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
