Bently Nevada 3300 XL 8mm Vibration Probe
Model: 330103-00-13-10-12-00
Configuration Breakdown:
┌─────────────┐ ┌────┐ ┌───────┐ ┌────┐ ┌───────┐ ┌────┐
│ 330103 │ → │ 00 │ → │ 13 │ → │ 10 │ → │ 12 │ → │ 00 │
├─────────────┤ ├────┤ ├───────┤ ├────┤ ├───────┤ ├────┤
│ Base 8mm │ │ 0mm│ │ 130mm │ │ 1m │ │FluidLoc│ │Std │
│ Probe │ │Smooth│ │ Body │ │Cable│ │+Click │ │Cert│
└─────────────┘ └────┘ └───────┘ └────┘ └───────┘ └────┘
Key Specifications
- ✔ 8mm PPS Sensing Tip
- ✔ 130mm Stainless Body
- ✔ 1.0m FluidLoc® Cable
- ✔ -52°C to +177°C Range
- ✔ 0.25-2.3mm Measurement
- ✔ M10×1 Thread Mount
Technical Details
| Output Signal | -1V to -17V DC |
|---|---|
| Optimal Gap | 1.27mm (50 mils) |
| Resistance | 7.59Ω ±0.50 |
| Weight | 323g/m (11.4 oz/ft) |
Installation Guide
- Mount: M10×1 thread (15mm max engagement)
- Position: 1.27mm from target surface
- Connect: Use shielded 3-conductor cable
⚠️ Critical: Do not expose to temperatures below -34°C (-30°F)
Package Contents
- 1 × 8mm vibration probe (130mm body)
- 1 × 1.0m FluidLoc® cable with ClickLoc connector
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
