Bently Nevada | 330103-00-06-10-12-00 | Proximity Probe

Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330103-00-06-10-12-00)

Description

A robust vibration monitoring sensor from Bently Nevada, this 3300 XL 8 mm Proximity Probe features a durable PPS tip and stainless steel case. Built for industrial reliability, it performs consistently across extreme temperatures and high humidity.

Technical Data

Brand: Bently Nevada
Model: 330103-00-06-10-12-00

Model Suffix Breakdown:

330103: Base model (M10x1 thread, no armor)
00: Unthreaded length (0mm)
06: Case length (60mm)
10: Total cable length (1.0m/3.3ft)
12: Connector type (Miniature coaxial ClickLoc with FluidLoc cable)
00: No agency approval required
Key Specs:

Linear Range: 2mm (80 mils) (0.25-2.3mm/10-90 mils)
DC Resistance: 7.59 ± 0.50Ω (1.0m cable)
Operating Temp (Standard): -52°C to +177°C (-62°F to +350°F)
Extended Temp (Tip): -52°C to +218°C (-62°F to +425°F)
Materials: PPS tip, AISI 303/304 stainless steel case
Weight: 323g/m (11.4 oz)
Humidity Resistance: <3% ASF change at 93% humidity (up to 56 days)

Installation Guide

Use 0.2-1.5mm² (16-24 AWG) wiring. Recommended: 3-conductor shielded triad cable (tinned). Max field wiring length: 305m (1,000ft) between probe and monitor.

Compatibility

Designed for 3300 XL Proximitor Sensors. Longer wiring may reduce high-frequency signal quality (check frequency response graphs).

Certification

Intrinsically safe (ia): Class I Zone 0, AEx/Ex ia IIC T5…T1 Ga
Nonincendive (nA/ec): Class I Zone 2, AEx/Ex nA/ec IIC T5…T1 Gc

Package Contents

1x 3300 XL 8 mm Probe (M10x1 thread, no armor)
1x 1.0m FluidLoc cable with Miniature coaxial ClickLoc connector
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
