Bently Nevada 200150-15-05 General-Purpose Accelerometer

What It Is

This is a general-purpose accelerometer for Trendmaster 2000 or Trendmaster Pro systems. Made in the USA, it works well and fits many uses, perfect for factory checks.

Model Details

200150: Main model for standard acceleration-to-velocity channel (-01).
-15: Mounting stud (3/8-24 to 3/8-16 UNC, 3/4 inch hex).
-05: Approved by CSA, ATEX, and IECEx.

Key Specs

Brand: Bently Nevada
Model: 200150-15-05
Sensitivity: 10.2 mV/(m/s²) (100 mV/g) at 80 Hz (±12%).
Range: ±245 m/s² (±25g).
Frequency: 10-1000 Hz (600-60,000 cpm) (±10% at 80 Hz).
Output: +2.5 ± 0.23 Vdc (bias).
Power: 4.7-5.5 Vdc.

Environment & Size

Temp: -40°C to +105°C (-40°F to +221°F).
Shock: 49,050 m/s² pk (5,000g pk).
Size: 17.5mm x 45.7mm (11/16 in x 1.8 in).
Weight: 58g (2.0 oz, typical).
Material: 316L stainless steel.

How to Install

Thread: 3/8-24 female.
Torque: 2.7-6.8 N•m (2-5 ft•lbf).

Works With

ProTIM standard acceleration-to-velocity channel (-01) and common factory uses.

Certifications

CSA, ATEX, IECEx approved.

What’s in the Box

1 Bently Nevada 200150-15-05 accelerometer.
Download PDF file here:200150, 200155 and 200157 Accelerometers Datasheet – 164986
