Allen Bradley HMI Display – 2711P-B10C10D6

Allen Bradley 2711P-B10C10D6 Panelview Plus 1000 HMI Terminal

The 2711P-B10C10D6 is a versatile HMI terminal from the Allen Bradley Panelview Plus 1000 series. It offers robust control with both touch and physical input methods.

Core Display & Input Specifications

• Brand & Model: This is the Allen Bradley 2711P-B10C10D6, a key member of the Panelview Plus 1000 family.
• Display Interface: It features a vivid 10.4-inch color TFT LCD with 640 x 480 pixel resolution.
• User Interaction: The terminal provides a combined tactile keypad and touchscreen for flexible operation.
• Visual Performance: The display uses 18-bit color depth and a long-life 50,000-hour CCFL backlight.

Electrical & Environmental Ratings

• Power Requirements: The HMI operates on DC power with a maximum consumption of 11 watts.
• Backup System: An integrated battery ensures a minimum 4-year lifespan at 25°C for clock backup.
• Operating Range: It performs reliably in an ambient temperature range of 0°C to 55°C.
• Thermal Management: The unit has a manageable heat emission of approximately 240 BTU per hour.
• Timekeeping Accuracy: The battery-backed real-time clock maintains ±2 minutes per month variance.

Internal Hardware & Memory

• Processing Memory: The system is equipped with 128 MB of CE-architecture RAM for application execution.
• Expansion Storage: Users can add storage via a removable 512 MB CompactFlash card.

Packaging & Installation Overview

• Package Contents: Your order includes the 2711P-B10C10D6 HMI unit, necessary mounting hardware, and user manuals.
• Shipping: We dispatch all products using reliable carriers such as FedEx, UPS, and DHL.
• Installation Guide: Mount the terminal in your control panel. Connect the DC power supply and your communication cables as required.

Frequently Asked Questions (FAQ)

• Q: Is this HMI terminal new and authentic?
  A: Yes, we supply only new and original Allen Bradley products, including the 2711P-B10C10D6.
• Q: What input methods does this model have?
  A: The 2711P-B10C10D6 offers both a tactile keypad and a touchscreen for user input.
• Q: What is the operating temperature range?
  A: This HMI is designed to operate in temperatures from 0°C to 55°C.
• Q: How much memory does it have for applications?
  A: It includes 128 MB of RAM and supports expansion with a 512 MB CompactFlash card.
• Q: What is the power consumption?
  A: Maximum power usage is 11 watts under normal operating conditions.
• Q: Is this item in stock?
  A: Yes, this model is typically available from our current inventory.
• Q: What is your processing and shipping time?
  A: We process and ship orders within 5 business days.
• Q: Do you offer international shipping?
  A: Yes, we ship worldwide using major logistics partners like DHL, FedEx, and UPS.
• Q: What is your return policy?
  A: We provide a 30-day return window for eligible, unused products.
