A06B-6150-H011 FANUC Power Supply Module | 13 kW 3-Phase 400-480VAC

FANUC A06B-6150-H011 Power Supply Module Overview

The A06B-6150-H011 from FANUC is a high-capacity power supply module for industrial systems. It uses a 3-phase input configuration with 400 to 480 VAC voltage range. This unit accepts 50 or 60 Hz input frequency for global compatibility. It converts AC power to a stable 565 to 679 VDC output voltage for downstream components.

• Substantial power capacity – The module delivers 13 kW rated output power. This capacity supports demanding servo systems and CNC applications.
• Efficient input current handling – It draws 24A at 400V input. This ensures consistent power delivery under varying load conditions.
• Wide operating temperature range – The unit functions reliably in ambient temperatures from 0°C to 55°C. It suits standard industrial environments.
• Robust storage tolerance – Engineers can store this module in temperatures from -20°C to 60°C. This provides flexibility for inventory management.
• High humidity resistance – It operates in ambient humidity up to 90% RH without condensation. This makes it suitable for humid production floors.

Technical Specifications

• Manufacturer: FANUC
• Product Line: A06B
• Model: A06B-6150-H011
• Module Type: Power Supply Module
• Input Voltage: 400–480 VAC
• Input Current: 24A at 400V
• Input Frequency: 50/60 Hz
• Number of Phases: 3-Phase
• Output Voltage: 565–679 VDC
• Rated Output Power: 13 kW
• Ambient Operating Temperature: 0°C to 55°C
• Ambient Storage Temperature: -20°C to 60°C
• Ambient Humidity: 90% RH or less (No condensation)
• Weight: 4.99 kg (11.00 lbs.)

Frequently Asked Questions (FAQ)

• Is this power supply module brand new and original?
  Yes, we supply a brand new and original FANUC A06B-6150-H011. It comes from authorized sources with full traceability.
• What is the current stock availability?
  We have this power supply module in stock. Orders ship within 5 business days after payment confirmation.
• Which shipping carriers do you use?
  We ship using DHL, FedEx, and UPS. We select the most suitable carrier based on your location.
• What output voltage does this module provide?
  The A06B-6150-H011 delivers 565 to 679 VDC output voltage. This range powers FANUC servo amplifiers and other industrial equipment.
• Can this unit operate in humid environments?
  Yes, it functions in humidity up to 90% RH without condensation. Ensure the installation location remains free from moisture buildup.
• What is the return policy?
  We accept returns within 30 days of delivery. The product must remain in original, unused condition.
