A06B-6124-H209 FANUC Servo Amplifier | Dual-Axis 18.2 A 400V Drive

FANUC A06B-6124-H209 Servo Amplifier Module – Dual-Axis High-Power Control

• FANUC engineered the A06B-6124-H209 as a dual-axis amplifier for efficient motion control.
• It delivers 18.2 A rms rated output current with 80 A peak current limit for heavy load
• Main power uses three-phase 400-480 VAC input for industrial compatibility.
• Control power runs on single-phase 200-240 VAC for separate circuit flexibility.
• It accepts -15% to +10% voltage deviation, handling load fluctuations smoothly.
• Power frequency is 50 Hz or 60 Hz with ±1 Hz tolerance for global use.
• The unit tolerates humidity up to 90% RH without condensation for stable operation.
• It handles vibration below 0.5G, ensuring reliable performance in dynamic environments.
• Operating temperature ranges from 0°C to 55°C, with storage from -20°C to 60°C.
• It provides 3ms instantaneous power failure guarantee for short interruptions.
• It weighs 8.62 kg (19.00 lbs) for straightforward installation.

Technical Specifications

• Manufacturer: FANUC
• Model: A06B-6124-H209 – Servo Amplifier Module
• Number of Axes: 2 axes (dual-axis)
• Rated Output Current: 18.2 A (rms)
• Nominal Current Limit: 80 A (peak)
• Main Power Supply: Three-phase 400-480 VAC
• Control Power Supply: Single-phase 200-240 VAC
• Voltage Deviation: -15% to +10%
• Power Frequency: 50 Hz / 60 Hz ±1 Hz
• Instantaneous Power Failure Guarantee: 3 ms
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -20°C to 60°C
• Humidity: 90% RH max (non-condensing)
• Operational Vibration: Below 0.5G
• Weight: 8.62 kg (19.00 lbs)
• Application: CNC systems, dual-axis motor control, automation

Frequently Asked Questions

• Q: Is the A06B-6124-H209 brand new and original?
  A: Yes. We sell brand new original FANUC units.
• Q: How many axes does this servo amplifier control?
  A: It controls two axes as a dual-axis amplifier module.
• Q: What is the output current rating?
  A: It delivers 18.2 A rms continuous and up to 80 A peak.
• Q: What power supply does it need?
  A: Main power needs three-phase 400-480 VAC. Control power needs single-phase 200-240 VAC.
• Q: How much voltage variation can it handle?
  A: It accepts -15% to +10% voltage deviation for stable operation.
• Q: How fast do you ship?
  A: We ship within 5 business days via DHL, FedEx, or UPS.
• Q: Can I return it if needed?
  A: Yes. We offer 30-day returns on unopened units.
• Q: What is the operating temperature range?
  A: It works from 0°C to 55°C and stores from -20°C to 60°C.
• Q: Does it handle power failures?
  A: Yes. It guarantees 3ms instantaneous power failure protection.
• Q: What vibration level can it tolerate?
  A: It operates reliably with vibration below 0.5G.
