Bently Nevada 3300 XL 8mm Proximity Probe – Model 330103-04-09-10-02-00

Why This Probe?

Engineered for industrial precision, this 3300 XL 8mm Proximity Probe combines a durable PPS tip with a stainless steel body. With a 1.0m standard cable and 90mm case length, it’s built to deliver reliable vibration monitoring in harsh environments.

Model Number Breakdown: 330103-04-09-10-02-00

330103: Base 8mm probe (M10x1 thread, no armor)
04: Unthreaded length (40mm)
09: Case length (90mm)
10: Total cable length (1.0m/3.3ft)
02: Connector (Miniature coaxial ClickLoc + standard cable)
00: No agency approval required

Core Specifications

Linear Range: 2mm (80 mils) (0.25-2.3mm/10-90 mils)
DC Resistance: 7.59 ± 0.50Ω (1.0m cable)
Operating Temp: -52°C to +177°C (-62°F to +350°F)
Extended Tip Temp: -52°C to +218°C (-62°F to +425°F)
Materials: PPS tip + AISI 303/304 stainless steel case
Humidity Performance: <3% signal change at 93% humidity (56 days max)

Installation & Compatibility

Wiring: Use 0.2-1.5mm² (16-24 AWG) wires. Shielded triad cable (tinned) recommended.
Max Distance: 305m (1,000ft) between probe and 3300 XL Proximitor Sensor. Longer wires may reduce high-frequency signals.
Optimal Gap: -9 Vdc (≈1.27mm/50 mils) for radial vibration.

Safety & Reliability

Intrinsically Safe (ia): Class I Zone 0, AEx/Ex ia IIC T5…T1 Ga
Nonincendive (nA/ec): Class I Zone 2, AEx/Ex nA/ec IIC T5…T1 Gc
Pressure Seal: Viton O-ring design (not pre-tested; contact for custom testing).

Package Includes

1x 3300 XL 8mm Probe (M10x1 thread, no armor)
1x 1.0m standard cable with Miniature coaxial ClickLoc connector

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
