Bently Nevada 3300 XL 8mm Proximity Probe | Model: 300103-00-05-10-02-00

Product Highlight

A rugged vibration sensor built for industrial reliability. This 3300 XL 8mm probe features a PPS tip, stainless steel body, and a 1.0m standard cable—engineered to perform in extreme temperatures and high humidity.

Model Breakdown: 300103-00-05-10-02-00

300103: Base 8mm probe (M10x1 thread, no armor)
00: Unthreaded length (0mm)
05: Case length (50mm)
10: Total cable length (1.0m/3.3ft)
02: Connector type (Miniature coaxial ClickLoc with standard cable)
00: No agency approval required

Key Tech Specs

Linear Range: 2mm (80 mils) (0.25-2.3mm/10-90 mils)
DC Resistance: 7.59 ± 0.50Ω (1.0m cable)
Operating Temp: -52°C to +177°C (-62°F to +350°F)
Extended Tip Temp: -52°C to +218°C (-62°F to +425°F)
Materials: PPS tip + AISI 303/304 stainless steel case
Humidity Resistance: <3% signal change at 93% humidity (56 days max)

Installation Tips

Use 0.2-1.5mm² (16-24 AWG) wiring. Best with 3-conductor shielded triad (tinned).
Max distance to monitor: 305m (1,000ft). Longer wires may reduce high-frequency signals.
Ideal gap for radial vibration: -9 Vdc (≈1.27mm/50 mils).

Safety Ratings

Intrinsically safe (ia): Class I Zone 0, AEx/Ex ia IIC T5…T1 Ga
Nonincendive (nA/ec): Class I Zone 2, AEx/Ex nA/ec IIC T5…T1 Gc

What’s Included

1x 3300 XL 8mm Probe (M10x1 thread, no armor)
1x 1.0m standard cable with Miniature coaxial ClickLoc connector

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
