330910-00-13-10-02-00 Bently Nevada 3300 NSv Proximity Probe

Bently Nevada 3300 NSv Proximity Probe Model 330910-00-13-10-02-00

• Brand & Model: Bently Nevada 330910-00-13-10-02-00 (3300 NSv Probe).
• Thread & Armor: M10X1 thread with full stainless steel armor.
• Unthreaded Length: 0 mm (option -00).
• Overall Case Length: 130 mm (option -13).
• Total Probe Length: 1.0 meter (39 inches, option -10).
• Connector Type: Miniature coaxial ClickLoc connector with standard cable (option -02).
• Agency Approval: Not required (option -00).
• Probe DC Resistance: 4.2 ± 0.5 ohms (center to outer conductor).

Technical Specifications

• Linear Range: 1.5 mm (60 mils) from 0.25 mm to 1.75 mm gap (approximately -1 to -13 Vdc).
• Recommended Gap Setting: 1.0 mm (40 mils).
• Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) with +12.5%/-20% interchangeability error.
• Deviation from Best Fit Straight Line (DSL): Less than ±0.06 mm (±2.3 mils).
• Frequency Response: 0 to 10 kHz ( +0, -3 dB typical) with up to 305 meters of field wiring.
• Minimum Target Diameter: 8.9 mm (0.35 in); recommended minimum 13 mm (0.5 in).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Probe Cable: 75 ohm coaxial with FEP insulation (0.5, 1, 5, or 7 meter total lengths).
• Extension Cable DC Resistance: Center conductor 0.220 Ω/m; Shield 0.066 Ω/m.
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
• Field Wiring: 0.2 to 1.5 mm² (16-24 AWG), use three-conductor shielded triad cable. Maximum length 305 meters.

Environmental & Mechanical Ratings

• Operating Temperature: -52°C to +177°C (-62°F to +351°F).
• Storage Temperature: -52°C to +177°C (-62°F to +351°F).
• Pressure Capability: Seals differential pressure with a Viton O-ring (not pressure tested before shipment).
• Recommended Torque (Probe Installation): Finger tight; maximum 0.56 N•m (5 in•lb).
• Minimum Bend Radius (with or without armor): 25.4 mm (1.0 in).
• Connector-to-Connector Torque (M10X1 case): Recommended 11.3 N•m (100 in•lb); maximum 33.9 N•m (300 in•lb).
• Thread Engagement Limit (3/8-24 or M10X1): Maximum 0.563 inches (first three threads: 22.6 N•m max).
• System Weight: Probe approximately 14 to 150 g (0.5 to 5.3 oz).

Frequently Asked Questions (FAQ)

• Q: Is this probe brand new and original?
  A: Yes, we provide only brand new, original factory-packed Bently Nevada probes.
• Q: Do you have the 330910-00-13-10-02-00 in stock?
  A: Yes, we normally keep this model in stock for immediate dispatch.
• Q: How long does delivery take?
  A: We ship within 5 days via FedEx, UPS, or DHL; typical transit time is 3-7 business days.
• Q: Can I return this probe if it does not fit my application?
  A: Yes, you may return it within 30 days as long as the packing remains unopened and the item is new.
• Q: Does this probe work with the old 3300 RAM extension cable?
  A: Yes, the 3300 NSv probe is mechanically and electrically interchangeable with the 3300 RAM series.
• Q: What is the maximum frequency response with long field wiring?
  A: 0-10 kHz typical with up to 305 meters of field wiring (refer to frequency response graphs).
