Bently Nevada 3300 NSv Vibration Probe
Model: 330907-05-30-50-12-00
Key Features:
- 5.0 meter (16.4 ft) FluidLoc cable
- M10x1 reverse mount thread
- Gold-plated ClickLoc connector
- Made in USA
- Optional COO available
Technical Specifications
| Measurement Range: | 0.25-1.75mm (10-70 mils) |
| Output Signal: | -1V to -13V DC |
| Resistance: | 5.3Ω ±0.7Ω |
| Operating Temp: | -34°C to +177°C |
| Recommended Gap: | 1.0mm (40 mils) |
Model Configuration
330907-05-30-50-12-00
├── 330907 : Base Model
├── 05 : M10x1 Thread
├── 30 : Standard Version
├── 50 : 5.0m Cable
├── 12 : FluidLoc Cable
└── 00 : No Approvals Required
Installation Guide
- Max torque: 7.5 N•m (66 in-lb)
- Thread engagement: 15mm maximum
- Use shielded triad cable (up to 305m)
- Seal material: Viton O-ring
Construction
- Probe tip: Chemical-resistant PPS
- Housing: 304 stainless steel
- Weight: 14-150g (0.5-5.3oz)
Applications
- Process compressors
- Gas turbines
- Power generation
- Oil & gas equipment
Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
