330708-00-10-90-11-05 – Armored 11 mm Probe | Bently Nevada

Bently Nevada 3300 XL 11 mm Proximity Probe (330708-00-10-90-11-05)

Main Features

Measures vibration and movement without touching machines
Strong 304 stainless steel body
9m FEP-insulated three-layer cable
FluidLoc cable with protected ClickLoc connector
Works in -51°C to +177°C temperatures

Model Code Details

330708: 11mm probe, 5/8-18 UNF thread (no armor)
00: Unthreaded length: 0 in
10: Case length: 1.0 in
90: Total length: 9.0m (29.5ft)
11: Small ClickLoc connector + protector + FluidLoc cable
05: Multiple approvals

Basic Specs

Brand: Bently Nevada
Tip Material: PPS
Cable Type: 75Ω three-layer (FEP insulated)
Resistance: 5.9±0.5 ohms (1m cable)
Weight: 0.17 Kg

How to Install

Use 5/8-18 UNF thread (max 0.938in tight)
Torque: 15.2 N•m (133 in•lb)
Connector: Hand-tight (max 5 in•lb)
Bend radius: At least 25.4mm (1.0in)

Works With & Certifications

Fits 3300 XL monitoring systems
Replaces old 7200 series sensors (need full upgrade)
Certifications: EMC, RFI/EMI protection, global approvals
Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
