330173-00-07-10-02-CN Bently Nevada – 3300 5mm Probe

Bently Nevada Precision Machinery Probe

Industrial-grade vibration sensor with enhanced 70mm case for critical equipment monitoring applications.

Core Specifications

Model: 330173-00-07-10-02-CN
Probe Size: 5mm with M8×1 threading
Cable: 1.0 meter length (3.3 feet)
Case: 70mm stainless steel housing

Electrical Performance

Power: -17.5 to -26 VDC
Current: <12mA consumption
Output: 50Ω resistance
Sensitivity: <2mV/V change
Temp Range: -35°C to +177°C
DC Resistance: 7.59±0.50Ω at 1m

Mechanical Properties

Tensile Strength: 222N (50lbf)
Max Torque: 7.3N·m (65in·lb)
Bend Radius: 25.4mm minimum
Materials: PPS tip + 304 SST case

Installation Notes

Requires 1.27mm target gap. Mount with 5.1N·m torque. Avoid temperatures below -34°C to prevent seal damage.

System Compatibility

Designed for Bently Nevada 3300/3500 systems. Works with turbines, compressors, and generators operating at 3000+ RPM.

Certifications

Meets country-specific approvals (CN option). Complies with industrial safety standards.

Package Contents

Probe with 1m cable, ClickLoc connector, documentation. Optional COO available.

Quality Assurance

12-month manufacturer warranty. Made in USA with precision calibration.

Industrial Application

Monitors steam turbine shaft vibrations in power generation facilities, detecting micron-level displacements at 50Hz operation.

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
