Bently Nevada 3300 XL 8mm Proximity Probe (330104-08-14-05-01-00)

Industrial-grade vibration sensor for precise machine monitoring. Made in USA for reliable performance.

Key Features

• 8mm diameter with M10x1 thread
• 140mm stainless steel case (AISI 303/304)
• Durable PPS plastic tip
• 0.5 meter cable with protected connector
• Viton® O-ring seal for pressure protection

Technical Specifications

• Part Number: 330104-08-14-05-01-00
• Unthreaded Length: 80mm
• Case Length: 140mm
• Resistance: 7.45Ω ±0.50
• Power: -17.5V to -26V DC
• Temp Range: 18°C to 27°C (64°F to 80°F)

Part Number Explained

• 330104 – Base model (8mm probe)
• 08 – 80mm unthreaded length
• 14 – 140mm case length
• 05 – 0.5m cable
• 01 – Protected ClickLoc connector
• 00 – No special approvals

Installation Guide

• Mount 1.27mm (50 mils) from target surface
• Use with AISI 4140 steel targets
• Works with 3300 XL monitoring systems

Common Uses

• Turbine vibration monitoring
• Compressor protection
• Large motor monitoring
• Power generation equipment

Package Includes

• 1 proximity probe
• 0.5m cable with connector

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
