21000-34-10-00-096-04-02 Bently Nevada Probe Housing

Bently Nevada 21000-34-10-00-096-04-02 Proximity Probe Housing Assembly

Key Technical Specifications

• Brand & Model: Bently Nevada 21000 with suffix codes defining exact configuration.
• Probe Option: 34 = 3300 XL 8 mm probe with connector protector with selectable hazardous area approvals.
• Probe Cable Length: 10 = 1.0 meter (39 inches).
• Probe Penetration: 096 = 9.6 inches.
• Fitting Option: 04 = one 3/4-14 NPT plug only.
• Mounting Thread: -02 = 3/4-14 NPT (required when standoff adapter is -00).
• Material: Aluminum body with 304 stainless steel sleeve.
• Maximum (C) + (D) Dimension (visible probe): 17.0 inches (43.18 cm).
• Maximum (C) + (D) Total: 32.9 inches (83.5 cm).
• Weight: 1.1 kg (2.4 lb) typical without fittings.
• Approvals & Compliance: CSA Type 4 enclosures, explosion-proof for hazardous areas, and fully compliant with API 670 Standard.
• Temperature & Environmental Tolerance: The assembly uses O-rings and thread seals for reliable sealing in industrial environments.

Frequently Asked Questions (FAQ)

• Q: Is the 21000 housing intrinsically safe?
  A: Yes, you can order hazardous area approved probes with this housing for intrinsically safe applications. CSA certifications apply.
• Q: What is the exact probe cable length?
  A: The code 10 specifies a 1.0 m (39 in) cable.
• Q: Do I need a standoff adapter for my installation?
  A: This version (-00) includes no standoff adapter. You must order a separate adapter if needed.
• Q: Can I use this housing outdoors in wet conditions?
  A: Yes, the CSA Type 4 enclosure rating makes it suitable for wet or dusty locations.
• Q: Is this assembly fully API 670 compliant?
  A: Yes, Bently Nevada designed the 21000 and 24701 housings to meet API 670 Standard for externally mounted proximity probes.
