140NOM25200 Schneider Electric DIO Head-End Adaptor Modicon Quantum

Schneider Electric 140NOM25200 DIO Head-End Adaptor | Modbus Plus Fiber Optic for Quantum

• Fiber optic communication: The 140NOM25200 features one Modbus Plus fiber optic port with TX/RX connectors. It also includes one Modbus RS232 port over twisted pair. The fiber port runs at 1 Mbit/s with 820 nm wavelength.
• Optical specifications: It supports multiple fiber types. Power loss budget reaches 11 dB for 62.5/125 µm, 16.5 dB for 100/140 µm, and 6.5 dB for 50/125 µm. Rise and fall time is 20 ns with 5 ns pulse width distortion.
• I/O capacity: It supports 30 input words and 32 output words. This allows efficient data exchange with remote I/O drops over fiber optic networks.
• Power and reliability: It consumes 4 watts of power. The bus current draw is 750 mA. It performs checksum, RAM, and processor verification for reliable operation.
• Built for demanding environments: It operates from 0 to 60 °C (32 to 140 °F). It holds marine certifications including DNV, GL, RINA, and RMRS. It also meets UL 508, CSA Class 1 Division 2, C-tick, and GOST standards. It withstands 10 V/m electromagnetic fields and 8 kV electrostatic discharge.
• Easy installation: The standard Quantum format fits any rack slot. IP20 protection suits cabinet mounting. It works up to 5000 meters altitude with 95% non-condensing humidity.

Key specifications

• Brand: Schneider Electric
• Model: 140NOM25200
• Type: DIO head-end adaptor with fiber optic Modbus Plus
• Ports: 1 x Modbus Plus fiber optic (TX/RX) + 1 x Modbus RS232 (RJ45)
• Transmission rate: 1 Mbit/s
• Wavelength: 820 nm
• Fiber types supported: 50/125 µm, 62.5/125 µm, 100/140 µm
• Power loss budget: 11 dB (62.5/125), 16.5 dB (100/140), 6.5 dB (50/125)
• Rise/fall time: 20 ns
• Pulse width distortion: 5 ns
• I/O words: 30 input / 32 output
• Power dissipation: 4 W
• Bus current: 750 mA
• Operating temp: 0…60 °C (32…140 °F)
• Storage temp: -40…85 °C (-40…185 °F)
• Humidity: 95% non-condensing
• Altitude: up to 5000 m (16404 ft)
• EMI immunity: 10 V/m (80…2000 MHz)
• ESD immunity: 8 kV air / 4 kV contact

Frequently asked questions

• Q: What fiber types work with the 140NOM25200?
  A: The 140NOM25200 supports 50/125 µm, 62.5/125 µm, and 100/140 µm multimode fiber. Each type has different power loss budget specifications.
• Q: What is the maximum distance for fiber optic Modbus Plus?
  A: With proper fiber and terminations, distances can reach several kilometers. Refer to the power loss budget to calculate maximum cable length based on your fiber type.
• Q: What remote I/O adaptors work with this head-end?
  A: This head-end works with Modbus Plus remote I/O adaptors. It is commonly paired with fiber-compatible remote drops for long-distance installations.
• Q: Can I remove the adaptor while the rack is powered?
  A: No. You must turn off the rack power before installing or removing the adaptor. Hot swapping can cause damage to the module or backplane.
• Q: Is this adaptor suitable for marine applications?
  A: Yes. The 140NOM25200 holds marine certifications including DNV, GL, RINA, and RMRS. It is approved for shipboard and offshore installations.
• Q: Do you have stock? How fast can you ship?
  A: Yes, we keep new original units in stock. We ship within 5 business days after payment. We use DHL, FedEx, or UPS.
• Q: Can I return it if I change my mind?
  A: Yes. You can return the adaptor within 30 days. It must be unused and in the original box.
