140NOA62200 Interbus Master Module | Generation 4 | Schneider Quantum

140NOA62200 Interbus Master Module – Generation 4 Performance

Key Features

• Serves as an Interbus master module for fieldbus networks.
• Belongs to Generation 4 Interbus family.
• Uses PCP V2.0 module profile.
• Provides master access method for network control.
• Works with Concept and ProWORX 32 software.
• Requires software version V 2.5 SR2 or later.

Communication Specifications

• Protocol: Interbus RS485 isolated.
• Speed: 500 kbit/s.
• Cable type: Twisted pair.
• Max distance between devices: 20 m (65.6 ft).
• Connectors: Two SUB-D 9 ports.
• One for Interbus link, one for additional connections.

Memory Capacity

• Firmware EPROM: 128 kB + 256 kB.
• Dual-port RAM: 2 kB.
• Data RAM: 256 kB + 32 kB.
• Interbus command sequence EEPROM: 64 kB.
• Multi-port RAM: 64 kB.
• Ample memory for complex applications.

Power and Compatibility

• Bus current requirement: 800 mA.
• Power dissipation: 4 W.
• Fits standard format Modicon Quantum racks.
• Works with local rack configurations.
• Compatible CPUs: 140CPU11303, 140CPU43412A, 140CPU53414B.
• Supports up to 6 modules with 140CPU11303.
• Supports up to 2 modules with 140CPU43412A or 140CPU53414B.

Status Indicators (LEDs)

• ACTIVE (green) – Communication with Quantum CPU active.
• RUN (green) – Firmware and module running.
• IS-B RUN (green) – Interbus functioning normally.
• F (red) – Module fault.
• Red LED – Initialization fault with DEA 202.
• Red LED – Interbus master not operational.
• Red LED – Interbus module reported fault.
• Red LED – Memory fault.
• Red LED – Peripheral bus fault.
• Red LED – Processor fault (master).
• Red LED – Remote bus fault.
• Yellow LED – One or more bus segments shut down.

Frequently Asked Questions

• Is the 140NOA62200 new and original?
  Yes, we supply only brand new, original Schneider Electric modules.
• Do you have stock?
  Yes, we have ample stock ready for shipment.
• How fast do you ship?
  We ship within 5 business days.
• Which carriers do you use?
  FedEx, UPS, or DHL – you can choose your preference.
• Can I return this module?
  Yes, we accept returns within 30 days.
• What protocol does this module use?
  It uses Interbus RS485 isolated protocol at 500 kbit/s.
• Which CPUs work with this module?
  It works with 140CPU11303, 140CPU43412A, and 140CPU53414B.
• What software supports this module?
  It works with Concept and ProWORX 32 (V 2.5 SR2 or later).
• How many LEDs does it have?
  It has multiple LEDs for status, including 1 green, 1 yellow, and several red indicators.
• What is the maximum cable distance?
  The maximum distance between devices is 20 meters (65.6 ft).
