140DDI36400 Schneider Electric Quantum 96-Input DC Module

140DDI36400 Schneider Electric Quantum 96-Point 24V DC Input Module

Key Technical Specifications

• Brand: Schneider Electric for Modicon Quantum platforms.
• Inputs: 96 DC inputs in 6 groups using positive logic (sink).
• Voltage: Works at 24 V DC nominal. Range is 19.2 to 30 V DC.
• Logic Levels: State 1 guaranteed from 15 to 30 V DC. State 0 at 5 V DC.
• Current: State 1 draws >= 2.5 mA. State 0 draws >= 0.7 mA.
• Impedance: Input impedance is 6700 Ohm for reliable signal reading.
• Protection: Max continuous input is 30 V. Handles 50 V decaying pulses.
• Speed: Turns on in 2 ms and off in 3 ms for stable response.
• Isolation: Provides 500 Vrms isolation between groups.
• Power: Dissipates 1.35 W plus 0.13 W per active point.
• LEDs: 96 green input status lights plus Active and Fault LEDs.
• Certifications: Meets CSA, UL, FM Class 1 Division 2, and C-tick standards.

Frequently Asked Questions (FAQ)

• Is this 140DDI36400 brand new?
  Yes. We sell only brand new original Schneider Electric modules.
• Do you have this module in stock?
  Yes. We keep stock ready to ship right away.
• How fast do you ship?
  We ship within 5 days after order confirmation.
• Which shipping companies do you use?
  We use DHL, FedEx, and UPS for fast delivery.
• Can I return this item?
  Yes. You can return items within 30 days in original condition.
• How many inputs does this module have?
  It has 96 inputs arranged in 6 groups for high-density applications.
• What voltage does this input module use?
  It uses 24 V DC nominal with a range of 19.2 to 30 V DC.
• What is the response time?
  It turns on in 2 ms and turns off in 3 ms.
• What logic type does this module use?
  It uses positive sink logic for all 96 input channels.
