140DDI35310 Schneider Electric Quantum DC Input Module

140DDI35310 Schneider Electric Quantum 32-Point 24V DC Input Module

Key Technical Specifications

• Brand: Schneider Electric for Modicon Quantum platforms.
• Inputs: 32 DC inputs in 4 groups using negative logic (source).
• Voltage: Works at 24 V DC nominal. Range is 19.2 to 30 V DC.
• Logic Levels: State 1 guaranteed from -30 to -15 V DC. State 0 from -5 to 0 V DC.
• Current: State 1 draws >= 2.5 mA. State 0 draws <= 0.5 mA.
• Impedance: Input impedance is 2400 Ohm for reliable signal reading.
• Protection: Input protection by resistor limiting. Max continuous input is 30 V.
• Speed: Turns on and off in 1 ms for fast response.
• Isolation: 1780 Vrms between group and bus. 500 Vrms between groups.
• Power: Dissipates 1.5 W plus 0.26 W per active point.
• LEDs: 32 green input status lights plus Active and Fault LEDs.
• Certifications: Meets UL, CSA, RINA, GOST, FM Class 1 Div 2, and RMRS standards.

Frequently Asked Questions (FAQ)

• Is this 140DDI35310 brand new?
  Yes. We sell only brand new original Schneider Electric modules.
• Do you have this module in stock?
  Yes. We keep stock ready to ship right away.
• How fast do you ship?
  We ship within 5 days after order confirmation.
• Which shipping companies do you use?
  We use DHL, FedEx, and UPS for fast delivery.
• Can I return this item?
  Yes. You can return items within 30 days in original condition.
• What voltage does this input module use?
  It uses 24 V DC nominal with a range of 19.2 to 30 V DC.
• What is the response time?
  It responds in 1 ms for both on and off transitions.
• What logic type does this module use?
  It uses negative source logic for the 32 input channels.
• Is this module compatible with positive logic systems?
  No. This 140DDI35310 uses negative logic for source inputs.
