Schneider Electric 140DAM59000 Mixed I/O Module – 16 Inputs / 8 Solid‑State Outputs

Key Technical Specifications

• ◆ Brand & Series: Schneider Electric Modicon Quantum – 140DAM59000 belongs to the trusted Quantum family.
• ◆ I/O Configuration: 16 discrete inputs (115V AC, 2 groups of 8) and 8 solid‑state outputs (115V AC, 2 groups of 4).
• ◆ Addressing: Requires 1 input word for inputs and 0.5 output word for outputs.
• ◆ Input Characteristics: Guaranteed ON state 79‑132V AC (60Hz) or 85‑132V AC (50Hz); OFF state 0‑20V AC. Input current ≤11mA (50Hz) / ≤13.2mA (60Hz).
• ◆ Output Ratings: Solid‑state outputs handle up to 4A per point, 8A per group, and 8A per module. Minimum load 5mA, max voltage drop <1.5V.
• ◆ Protection & Diagnostics: Outputs protected by RC snubber and internal 5A fuse per group. LED indicators for bus active, faults, and I/O status.
• ◆ Isolation: 1000Vrms between groups, 1780Vrms between channels and bus.
• ◆ Environmental Resistance: Operates 0‑60°C, 95% humidity non‑condensing; certified immunity to ESD (4kV contact, 8kV air) and radiated fields (10V/m).
• ◆ Power & Weight: Bus current 250mA; dissipation 5.5W + (1.1 x load current). Net weight 0.45kg (0.99lb).

Isolation, Environmental Tolerance & Compliance

• ◆ Reinforced Isolation: Channels to bus withstand 1780Vrms for one minute; groups are isolated to 1000Vrms.
• ◆ Wide Ambient Range: Certified for operation from 0°C to 60°C and storage from -40°C to 85°C, withstanding 95% relative humidity without condensation.
• ◆ EMC / Immunity: Meets IEC 801‑2/‑3 standards: 4kV contact / 8kV air discharge and 10V/m radiated immunity (80‑1000MHz).
• ◆ Approvals: UL 508, CSA C22.2 No 142, cUL, and FM Class 1 Division 2 suitable for hazardous locations.
• ◆ Altitude: Safe for installation up to 5000m (16404ft).

Frequently Asked Questions (FAQ)

• Q: Can I use the 140DAM59000 with both AC inputs and outputs on the same module?
  A: Yes, it provides 16 AC inputs and 8 solid‑state AC outputs, all operating at 115V AC, making it ideal for mixed control applications.
• Q: What is the maximum load current per output point and per group?
  A: Each output point handles up to 4A, with a group limit of 8A (two groups of four). Total module output current must not exceed 8A.
• Q: How are the outputs protected against shorts or overloads?
  A: Each output group includes an internal 5A fuse. Additionally, RC snubbers provide transient suppression.
• Q: What are the guaranteed ON and OFF voltage thresholds for inputs?
  A: For 60Hz, ON requires 79‑132V; for 50Hz, 85‑132V. OFF state is guaranteed below 20V AC.
• Q: Does the 140DAM59000 provide isolation between input and output sections?
  A: Inputs and outputs are in separate groups with 1000Vrms isolation between them, and 1780Vrms isolation to the bus.
• Q: What diagnostic LEDs does the module feature?
  A: It includes green Active LED, red Fault LED, plus two green output‑on LEDs, two red input‑fault LEDs, and two red output‑fault LEDs.
