140ARI03010 – Analog Input Module Schneider Electric

Schneider Electric Modicon Quantum RTD Temperature Input Module

Core Specifications & Technical Details

• Brand: Schneider Electric
• Series: Modicon Quantum
• Model: 140ARI03010
• Product Type: RTD Temperature Analog Input Module
• Total Channels: 8 differential input channels

Temperature Input & Sensor Specifications

• This module provides eight dedicated temperature input channels.
• It supports a wide variety of RTD sensor types: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni200, Ni500, Ni1000.
• The module covers multiple temperature ranges from -200°C to +850°C.
• It is compatible with 2-wire, 3-wire, and 4-wire sensor connection methods.
• The analog input resolution is 13 bits for precise measurement.
• Input impedance is very high at >= 10 MOhm to minimize measurement error.

Accuracy & Performance Details

• It achieves excellent absolute accuracy of 0.1 °C under specified conditions.
• The linearity error is very low at ±0.01% of full scale.
• Accuracy drift is only ±0.5 °C at 25°C (77°F) and ±0.9 °C from 0 to 60°C.
• The update time depends on wiring: 640 ms for 2/4-wire, 1200 ms for 3-wire sensors.
• The module actively detects and reports faults like broken sensor wires.

Environmental Ratings & Safety Isolation

• The operating air temperature range is 0 to 60°C (32 to 140°F).
• Storage temperature range is -40 to 85°C (-40 to 185°F).
• It is rated for operation up to 5000 meters (16404 ft) in altitude.
• It withstands up to 95% relative humidity without condensation.
• Isolation between channels and the bus is 1780 V AC / 2500 V DC for 60 seconds.
• It offers high resistance to electrostatic discharge and electromagnetic fields.

Installation, Diagnostics & Packaging

• The module uses a standard Quantum format for easy rack installation.
• LED status indicators show bus communication, external faults, and per-channel status.
• PLC addressing requires 9 input words for the eight channels and status data.
• The bus current requirement is low at 200 mA from the Quantum backplane.
• Package weight is approximately 440 grams (15.5 oz).
• We supply only brand new and original 140ARI03010 modules.
• Orders ship promptly via DHL, FedEx, and UPS global courier networks.

Frequently Asked Questions (FAQ)

• Q: Is this 140ARI03010 module new and authentic Schneider Electric?
  A: Yes, every module we sell is 100% new, original, and authentic from Schneider Electric.
• Q: Do you have stock, and what is the lead time for shipment?
  A> We maintain stock for fast delivery. Orders are processed and shipped within 5 business days.
• Q: Which RTD sensor types does this module support?
  A: It supports all common Pt and Ni RTDs, including Pt100, Pt1000, Ni100, and Ni1000, in 2, 3, or 4-wire configurations.
• Q: What is the measurement accuracy and update speed?
  A: Accuracy is excellent at 0.1°C. Update speed is 640ms (2/4-wire) or 1200ms (3-wire) per channel scan.
• Q: What is the electrical isolation for safety?
  A: It features high 1780V AC isolation between the field channels and the PLC bus for protection.
• Q: What is your return policy for this item?
  A> We offer a 30-day return policy for items in new, unopened condition with original packaging.
