Strategic Guide: Upgrading from Legacy DH+ to Modern Ethernet/IP Networks
A Phased Approach for Minimal Disruption
Are you managing aging Allen-Bradley Data Highway Plus (DH+) systems? Modernization is essential for reliability and data access. However, a full rip-and-replace strategy often causes excessive downtime. This guide outlines a proven, step-by-step migration plan. Consequently, you can achieve a smooth transition to high-speed EtherNet/IP.
Conducting a Comprehensive Network Assessment
Begin your modernization project with a thorough audit. Document every device on your DH+ network, such as PLC-5 or SLC 500 controllers. Record specific model numbers and firmware versions precisely. Moreover, assess current communication performance and cable integrity. This analysis forms your essential planning foundation. Therefore, you avoid unforeseen compatibility issues later.
Choosing Modern Conversion Hardware and Modules
Selecting the correct interface hardware is critical for success. Modern ControlLogix Ethernet modules, like the 1756-EN2T series, serve as ideal replacements. These modules plug directly into a new chassis. Furthermore, they handle robust protocol translation seamlessly. This approach preserves your legacy PLC investment. As a result, you gain Ethernet connectivity without processor replacement.
Implementing a Phased Migration Plan
Adopt a staged implementation to maintain production. First, install a new ControlLogix chassis with an Ethernet module. Next, connect it to the existing DH+ network using a 1756-DHRIO module. Then, migrate control logic and data points incrementally. This method typically reduces system downtime by over 70%. Moreover, it allows for testing at each stage.
Author’s Insight: In my experience, this phased approach is the single most effective factor for project success. It turns a high-risk overhaul into a manageable series of small, low-risk steps, greatly reducing resistance from operations teams.
Configuring Network Topology and Addressing
Design a reliable star topology for your new EtherNet/IP network. Assign static IP addresses to all new devices for network stability. Configure the DHRIO module’s bridging tables meticulously. Additionally, segment networks logically using managed switches. Proper configuration ensures flawless data routing. Therefore, your HMI and SCADA systems access data reliably.
Validating System Performance and Data Transfer
After configuration, rigorous testing is mandatory. Verify all data exchange points between legacy and new systems. Use diagnostic tools like RSLinx Classic to monitor network load. You will see a dramatic speed increase from DH+’s 230.4 kbps to Ethernet’s 100 Mbps or 1 Gbps. Finally, confirm that critical I/O data transfers meet required scan times. This validation step builds operational trust.
Ensuring Long-Term Support and Enhanced Security
Once operational, shift focus to sustainability and security. Implement contemporary measures like VLAN segmentation using managed switches. Establish a regular schedule for firmware updates. This upgrade future-proofs your system for Industrial IoT (IIoT) applications. Moreover, it unlocks potential for advanced data analytics and cloud connectivity.
Author’s Comment: The security aspect is no longer optional. Modern industrial networks are targets. Upgrading from DH+ isn’t just about speed; it’s your first real opportunity to implement foundational cybersecurity practices like segmentation and access control, which are impossible on legacy serial networks.
Practical Application Scenario
Consider a bottling plant with a critical PLC-5 line controller. The phased migration allowed a new ControlLogix PAC to be installed alongside. The 1756-DHRIO module bridged the networks. Operators migrated the control logic during scheduled weekly maintenance. Consequently, the line converted to Ethernet control over six weeks with zero unplanned downtime. The new system now provides real-time performance data to the plant floor HMI and the maintenance dashboard.
Frequently Asked Questions (FAQ)
Q1: Can I keep my old PLC-5 processors after the upgrade?
A1: Yes, absolutely. The core strategy uses protocol conversion modules like the 1756-DHRIO. This allows your existing PLC-5 or SLC controllers to communicate over the new Ethernet network without being replaced.
Q2: What is the primary benefit of upgrading from DH+ to EtherNet/IP?
A2: The key benefits are vastly higher data speed (from kbps to Gbps), improved reliability, easier diagnostics, and seamless integration with modern HMIs, historians, and IIoT platforms. It also future-proofs your communication infrastructure.
Q3: Is total system downtime required for this migration?
A3: No. A properly planned phased migration specifically avoids total downtime. You install new hardware in parallel and migrate control functions incrementally, keeping the existing system running for most of the process.
Q4: What happens to my existing DH+ wiring?
A4: The old DH+ trunk cable is typically decommissioned once all devices are migrated. However, during the transition, new Ethernet cabling is run alongside it. The final network will use standard Ethernet cabling (CAT5e/6) and topology.
Q5: How does this upgrade improve system security?
A5: EtherNet/IP enables the use of modern network security features. You can implement managed switches with VLANs, firewalls, and access control lists. These features are not possible with the open, serial architecture of DH+, significantly enhancing your cybersecurity posture.
