VFAS3-4110KPC Toshiba AS3 Series | 460VAC 211A Open Frame Drive

Toshiba AS3 VFAS3-4110KPC: 150HP AC Drive with EtherNet/IP

The VFAS3-4110KPC is a Toshiba AS3 series high-performance drive. It controls 460VAC motors with 150HP power. Use it for V/Hz, FOC with encoder, or torque control. This unit includes EtherNet/IP and RS-485 ports. It suits heavy industrial applications. The open frame design fits standard electrical cabinets.

Power and Input Specifications

• Brand: Toshiba VFAS3-4110KPC, AS3 series, A6 frame size
• Voltage: 460VAC input and output, 3-phase, 150HP
• Current: 211A rating, 250A for variable torque
• Braking: External dynamic braking unit required
• Filter: Integrated EMI filter and DC reactor

Control and Performance

• Control modes: V/Hz, FOC with encoder, sensorless vector, torque mode
• Frequency range: 0.1Hz to 590Hz output
• Carrier frequency: 1kHz to 8kHz, field adjustable
• Motor types: 3-phase induction and permanent magnet AC
• STO: Safe Torque Off built-in

Communication and I/O

• EtherNet/IP: (2) RJ45 ports, 10/100 Mbps, embedded web server
• RS-485: (1) RJ45, Modbus RTU slave
• Digital inputs: 8 points, 24VDC, sink/source
• Digital outputs: 3 relay, 1 Form C SPDT, 2 Form A SPST, 2A each
• Analog inputs: 3 channels, ±10VDC or 0-20mA, 11-bit
• Analog outputs: 2 channels, 0-10VDC or 0-20mA, 10-bit
• Expansion: Optional EtherCAT, encoder, I/O cards

Environmental and Enclosure

• Enclosure: Open frame, IP00 rating, panel or wall mount
• Temperature: -15°C to 50°C operating
• Frame: A6 size, heavy-duty construction
• Cooling: Requires cabinet ventilation, IP00 maximizes airflow
• Battery: CR2032 installed, retains encoder parameters
• Hazard class: UN3091, lithium metal, 0.06g

Installation and Mounting

• Mount vertically on panel inside electrical enclosure
• Provide adequate cabinet cooling for 150HP operation
• Use screw terminals, external fuse required
• Separate Ethernet and power cables to prevent noise
• External braking unit ordered separately

What You Receive

• (1) Toshiba VFAS3-4110KPC drive with reactor and filter
• (1) CR2032 battery, pre-installed
• Quick start guide and terminal identification labels
• Mounting hardware for A6 frame
• Shipping: FedEx, UPS, DHL. Dispatch within 5 days
• Stock: In stock. 30-day returns accepted

Frequently Asked Questions

• Does VFAS3-4110KPC include a braking resistor?
  No. This 150HP drive needs an external dynamic braking unit. Order separately.
• What is the IP rating?
  IP00 open frame. Install inside a NEMA or UL enclosure.
• Can I add EtherCAT communication?
  Yes. Optional EtherCAT card plugs into A6 frame option slot.
• What motor types are compatible?
  3-phase induction and permanent magnet AC motors up to 150HP.
• Is STO hardware included?
  Yes. Safe Torque Off comes standard on all AS3 drives.
