Toshiba VFAS3-4075PC AC Drive | 10HP 460V 3-Phase

Toshiba AS3 Series VFAS3-4075PC: 10HP High-Performance AC Drive

The VFAS3-4075PC is a Toshiba AS3 series drive. It delivers 10HP from 460VAC 3-phase input. This UL Type 1 unit fits panel or wall mount. Use it with 3-phase induction and permanent magnet AC motors.

• Power Ratings: VFAS3-4075PC provides 16.5A continuous output. Variable torque rating reaches 23.5A. Designed for 10HP constant torque applications.
• Control Range: Drive runs 0.1 Hz to 590 Hz. Carrier frequency adjusts 1-16 kHz. Input accepts 4-20 mA, +/-10 VDC, or pulse train. Control modes: V/Hz, FOC, encoder, or torque.
• Environment: Works at -15°C to 50°C. IP20 protection. UL Type 1 enclosure. Built-in EMC filter and DC reactor. Integrated dynamic braking.
• Network: Two RJ45 Ethernet ports. Supports EtherNet/IP, Modbus TCP, web server. One RJ45 RS-485 port. Optional EtherCAT card available.
• Safety: Safe Torque Off (STO) built-in. Reverse capability included. No internal bypass.
• Analog I/O: Three analog inputs with 11-bit resolution. Two analog outputs with 10-bit resolution.
• Digital I/O: Eight 24 VDC inputs. Sinking or sourcing. Three relay outputs. One Form C SPDT, two Form A SPST. 2A rating per point.
• Dimensions: Frame size A2. Compact design for space-saving installation.
• Installation: Screw terminals. User supplies external fuse. Conduit box included. Panel or wall mount.
• Box Contains: One Toshiba VFAS3-4075PC drive unit. Built-in DC reactor and EMC filter. Conduit box attached. CR2032 battery installed.

Frequently Asked Questions

• Is this drive brand new? Yes, all VFAS3-4075PC units are factory-sealed and 100% new.
• Do you have stock? Yes, we keep this model in stock. Ready to ship.
• When do you ship? We ship within 5 business days.
• Which couriers? DHL, FedEx, and UPS.
• Return policy? 30-day returns. Unit must be unused in original box.
• What motors work? 3-phase induction and permanent magnet AC motors.
• Battery included? Yes, CR2032 installed. Replacement part D0-MC-BAT.
• Control modes? V/Hz, FOC with encoder, sensorless FOC, or torque control.
• Ethernet speed? 10/100 Mbps. Two RJ45 ports.
• What is frame size? A2 frame. Compact size for 10HP applications.
• Current rating? 16.5A continuous. 23.5A variable torque.
