Temperature Control Module GE Fanuc IC693TCM302

GE Fanuc IC693TCM302 Temperature Module

The IC693TCM302 controls temperature for GE Fanuc Series 90-30 PLCs. It reads 8 thermocouples and gives control outputs.

Technical Details

• Brand: GE Fanuc
• Model: IC693TCM302
• Series: 90-30
• Channels: 8 inputs / 8 outputs
• Output Voltage: 18-30V DC
• Load Current: 100 mA
• Internal Power: 150 mA at 5V DC
• External Power: 18-36V DC
• Leakage Current: 0.1 mA max

Key Features

• Eight thermocouple inputs
• Eight control outputs
• Twelve status LED lights
• Auto or manual modes
• Fault detection
• Open circuit alerts
• Reverse polarity check

Temperature Ranges

• Operation: 0°C to 55°C
• Storage: -40°C to 85°C
• Thermocouple impedance: 30Ω max
• Works in tough places
• Industrial grade parts

Power Requirements

• External power: 18-36V DC
• Inrush current: 2.5A
• Internal use: 150mA at 5V
• Load current: 100mA
• Low leakage: 0.1mA max

Questions

• How many inputs? Eight thermocouple inputs.
• What output voltage? 18-30V DC range.
• Power needs? 18-36V DC external.
• Status lights? Twelve LED indicators.
• Operating modes? Auto and manual modes.
