Schneider Electric Hot Standby Module 140CHS11000

Schneider Electric 140CHS11000 Hot Standby Module

Core Technical Specifications

• Brand & Model: This module is manufactured by Schneider Electric under model number 140CHS11000.
• Product Type: It functions specifically as a Hot Standby Module for processor redundancy.
• Compatibility: The module works with all legacy 140CPU (LL984) and 140CPU43412A/534 (IEC) units.
• I/O System Support: It is compatible with Quantum, 800 Series, and Sy/Max (remote I/O only) systems.
• Communication: Data transmits at a high speed of 10 Mbit/s over fiber optic cable.
• Switching Performance: The module boasts a fast switching time between 13 to 48 milliseconds.
• Power Draw: It requires a bus current of 700 mA for normal operation.

Physical & Environmental Specifications

• Connection: It uses 1 RJ45 connector for fiber optic receiver and 1 for transmitter.
• Status Indication: Five LEDs show status: standby, I/O comms, control process, ready, and errors.
• Operating Temperature: It performs reliably from 32 to 140 °F (0 to 60 °C).
• Immunity: The module has strong RFI immunity (27–1000 MHz at 10 V/m) and ESD protection (4kV contact, 8kV air).
• Form Factor: The module comes in a standard Quantum format with a net weight of 2.34 lbs.

Packaging & Ordering Information

• Packaging Levels: The 140CHS11000 ships as a single unit (PCE) or in a master carton (S03) of 7 units.
• Unit Package: The single unit box measures 12.20 x 6.50 x 1.97 inches and weighs 17.6 oz.
• Master Carton: The carton of 7 measures 15.75 x 11.81 x 11.81 inches and weighs 8.85 lbs.
• Shipping: We ship globally via reliable carriers like FedEx, UPS, and DHL for fast delivery.

Frequently Asked Questions (FAQ)

• Is the 140CHS11000 module new and original?
  Yes, we supply only new and original Schneider Electric modules.
• What software is required for the 140CHS11000?
  It requires Concept V2.0 or higher or ProWORX 32 NxT V2.0 for configuration.
• Do you have the 140CHS11000 in stock?
  Yes, we maintain stock of this critical hot standby module for immediate needs.
• What is the lead time for shipping?
  We typically process and ship orders within 3-5 business days.
• What is the fiber optic cable length?
  The module uses a short 3-meter (9.8 ft) fiber optic pigtail for interconnection.
