Schneider Electric 140CRA93100 RIO Drop Adaptor Module

Schneider Electric Modicon Quantum 140CRA93100 RIO Drop Adaptor Module

The Schneider Electric 140CRA93100 is a RIO drop adaptor module for Modicon Quantum systems. It connects remote I/O using a 75 Ohm coaxial cable. This single-channel module supports data transmission at 1.544 Mbit/s. It allows connection of up to 27 I/O expansion modules to your Quantum controller.

Main Technical Features

• This Schneider Electric module adapts remote I/O for Quantum.
• It uses a 75 Ohm coaxial cable for reliable communication.
• Transmission speed is 1.544 Mbit/s with 35 dB dynamic range.
• It supports up to 27 I/O expansion modules per channel.

Communication & Electrical Specs

• Connection: 1 female F-type connector (elbowed, single cable).
• Cable type: 75 Ohm coaxial.
• Speed: 1.544 Mbit/s.
• Isolation: 500 V DC between coaxial center and ground.
• Power use: 3W per channel.
• Bus needs: 600 mA per channel.

Diagnostics & System Integration

• The module provides startup and runtime diagnostics.
• It checks executive checksum and RAM address/data.
• Standard module format fits Quantum racks easily.
• Designed for seamless integration with Quantum platform.

Environmental Specifications

• Works in 0 to 60°C (32 to 140°F) temperatures.
• Stores in -40 to 85°C (-40 to 185°F) conditions.
• Handles up to 95% humidity (no condensation).
• Good for heights up to 5000 meters.
• Resists ESD: 4kV contact, 8kV air.
• Resists EMI: 9.1V/m (80-1000MHz).

Packaging & Shipping Details

• We supply new, original 140CRA93100 modules.
• Each unit comes in factory packaging.
• Box size: 31.0 cm × 16.5 cm × 4.7 cm.
• Weight: about 509 grams.
• Ships in 5 days via FedEx, UPS, or DHL.

Frequently Asked Questions

• Q: Is this a genuine Schneider Electric module?
  A: Yes, every 140CRA93100 is authentic and factory-new.
• Q: What cable does this adaptor use?
  A: It requires a 75 Ohm coaxial cable for connection.
• Q: How many I/O modules can it support?
  A: Up to 27 I/O expansion modules per channel.
• Q: What is the data transmission speed?
  A: 1.544 Mbit/s with good signal quality.
• Q: What is your shipping policy?
  A: We ship within 5 days and offer 30-day returns.
