Schneider 140CRP93100 RIO Head Adaptor | Quantum

Schneider Electric 140CRP93100 RIO Head-End Adaptor Module

The Schneider Electric 140CRP93100 is a RIO head-end adaptor module. It works with the Modicon Quantum automation platform. This module sits in the main processor rack. It controls communication with up to 31 remote drops. The 140CRP93100 uses the S908 network for data transfer. It offers reliable performance for large control systems.

Main Specifications

• Product range: Modicon Quantum automation platform
• Product type: RIO head-end adaptor module
• Works with: Quantum 200/500/800 series and Symax systems
• GTIN: 3595861133754
• Category: US1PC2118155
• Discount schedule: PC21
• Return policy: Yes, this item is returnable

Network Features

• Supports up to 31 remote drops on one network
• Speed: 1544 Mbit/s for fast communication
• I/O per drop: 64 input words and 64 output words
• Signal range: 35 dB dynamic range
• Cable type: 75 Ohm coaxial cable
• Isolation: 500 V DC between center and ground

Connector and Power

• One elbowed female F-type connector for single cable
• Power use: 3 W for one channel
• Bus current: 600 mA for one channel
• Startup checks: memory and LAN controller tests
• CE marking for Europe

Environmental Ratings

• Working temperature: 32 to 140 °F (0 to 60 °C)
• Storage temperature: -40 to 185 °F (-40 to 85 °C)
• Humidity: 95% with no condensation
• Max altitude: 16404 feet (5000 meters)
• Static protection: 4 kV contact, 8 kV air
• Field protection: 9.1 V/m at 80-1000 MHz

Certifications

• FM Class 1 Division 2 for hazardous areas
• UL 508 certified
• CUL certified for Canada
• CSA C22.2 No 142 compliant
• Meets IEC 801-2 and 801-3 standards

Package Details

• Package type: PCE (single unit)
• One module per package
• Height: 1.69 inches (4.3 cm)
• Width: 6.42 inches (16.3 cm)
• Length: 12.36 inches (31.4 cm)
• Weight: 17.6 oz (500.0 g)

How to Install

• Place the Schneider 140CRP93100 in the main Quantum rack.
• Plug the coaxial cable into the F-type connector.
• This module acts as the main controller for remote drops.
• Make sure the S908 network has proper termination.
• The angled connector saves space in the cabinet.
• Press firmly to seat the module on the backplane.

Package Contents

• 1x Schneider Electric 140CRP93100 head-end module
• Brand new in factory packaging
• We ship with FedEx, UPS, and DHL worldwide
• In stock and ships within 5 days
• 30-day returns from delivery date

Frequently Asked Questions

• What is the 140CRP93100 used for? It is the main module in the processor rack. It manages all remote I/O drops on the S908 network.
• What is CRP vs CRA? CRP is the head-end in the main rack. CRA is the remote module in the drop rack.
• How many drops can it handle? It can handle up to 31 remote drops on one network.
• What cable do I need? You need 75 Ohm coaxial cable for the S908 network.
• How much I/O per drop? Each drop handles 64 input and 64 output words.
• What temperature range works? It works from 0 to 60°C (32 to 140°F).
• Is it safe for hazardous areas? Yes, it has FM Class 1 Division 2 certification.
• Do you ship to my country? Yes, we ship worldwide with FedEx, UPS, and DHL.
