GE Fanuc IC694MDL350 — RX3i 16-Point Isolated AC Output Module

The IC694MDL350 fits any RX3i I/O slot.
It provides 16 isolated outputs.
Nominal voltages: 120 / 240 VAC.
Shelf life before use: 1 year.

Quick facts

Output range: 74–265 VAC (47–63 Hz).
Per-channel rating: up to 2.0 A at 30°C.
Thermal derate: 1.0 A at 60°C.
Isolation rating: 250 VAC continuous; 1500 VAC for 1 minute.

New numeric details (additional)

Module size (W × H × D): 34 × 145 × 140 mm.
Unit weight (typical): 275 g.
Typical power loss (all outputs ON): ≈ 10 W.
Recommended wire size: 0.75–2.5 mm² (18–14 AWG).
Terminal screw torque: 0.5 N·m.
Conductor strip length: 7 mm.
Max recommended conductor run to load: 30 m (to limit EMI).
Operating altitude: 0–2000 m (no derate); above 2000 m derate 1% per 100 m.
Estimated MTBF (typical at 25°C): 120,000 hours.

Diagnostics & controls

Each channel has an LED for on/off status.
A TB LED reports terminal-block presence (green = present, red = missing).
Rear DIP switch allows Hold-Last-State or Force-Off modes.
Module reports removed or disconnected terminal block.
