PSM Module GE Fanuc IC694PSM001

GE Fanuc IC694PSM001 RX3i PSM Module for Power Monitoring

Product Overview

The IC694PSM001 monitors two independent power grids in an RX3i PLC. It allows hot-swapping without stopping the system. The module measures voltage, current, frequency, and phase angles using DSP technology. It works with single-phase and three-phase systems in wye or delta. It connects to terminal assemblies and cables for full power monitoring.

IC694PSM001 suits generator control, fault monitoring, power tracking, and lowering demand penalties. It ensures safe grid and generator synchronization.

Technical Specifications

• Manufacturer: GE Fanuc
• Series: RX3i PacSystems
• Part Number: IC694PSM001
• Product Type: PSM Module
• Hot Swapping: Supported
• Purpose: Monitor 2 Independent Power Grids
• Technology: DSP (Digital Signal Processor)
• Supported Power Systems: Single-phase, Wye 3-phase, Delta 3-phase
• Inputs: 4 current and 3 voltage inputs per grid
• Measurements: RMS voltage, RMS current, RMS power, frequency, phase angles
• Compatible CPUs: RX3i with firmware 7.70 or newer
